12-Bit 170 MHz Video and Graphics
Digitizer with Quad HDMI 1.3 Receiver
Preliminary Information
ADV7604
Pr.
0
Information furnished by Analog Devices is believed to be accurate and reliable. However, no
responsibility is assumed by Analog Devices for its use, nor for any infringements of patents or other
rights of third parties that may result from its use. Specifications subject to change without notice. No
license is granted by implication or otherwise under any patent or patent rights of Analog Devices.
Trademarks and registered trademarks are the property of their respective owners.
One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.
Tel: 781.329.4700
www.analog.com
Fax: 781.461.3113 ©2008 Analog Devices, Inc. All rights reserved.
FEATURES
Three 12-bit ADCs
ADC sampling rates up to 170 MHz
12-channel analog input mux
525i/625i component analog input
525p/625p component progressive scan support
720p/1080i/1080p/1250i component HDTV support
Digitizes RGB graphics up to 1600 × 1200 at 60 Hz (UXGA)
VBI data slicer (including teletext)
Simultaneous HDMI and analog video sync processing
Ultralow jitter digital PLL
Quad HDMI Rx
4:1 multiplexed HDMI receiver
HDMI 1.3, DVI 1.0
225 MHz HDMI receiver
Repeater support
High-bandwidth Digital Content Protection (HDCP 1.3)
36-/30-/24-bit deep color support
HDMI 1.3-compatible audio interface
Programmable/adaptive equalizer for cable lengths up to
30 meters
Internal EDID RAM
EDID with HDMI cable power support
CEC support
General
S/PDIF (IEC90658-compatible) digital audio output
Highly flexible output interface
12-bit 4:4:4/8-bit 4:2:2 DDR pixel output interface
Dual STDI function support standard identification
2 any-to-any 3 × 3 color space conversion matrixes
2 programmable interrupt request output pins
Advanced sync processing for robust sync extraction of
poor video sources
AV.Link support
APPLICATIONS
Advanced TV
PDP HDTVs
LCD TVs (HDTV ready)
LCD/DLP® rear projection HDTVs
CRT HDTVs
LCOS™ HDTVs
AVR video receivers
LCD/DLP front projectors
HDTV STBs with PVR
CRT HDTVs
DVD recorders with progressive scan input support
GENERAL DESCRIPTION
The ADV7604 is a high quality, single chip, multiformat video
decoder, graphics digitizer with an integrated 4:1 multiplexed
High-Definition Multimedia Interface (HDMI™) receiver.
The ADV7604 contains one main component processor (CP),
which processes YPrPb and RGB component formats, including
RGB graphics. The CP also processes the video signals from the
HDMI receiver. The ADV7604 can operate in quad HDMI and
analog input mode, thus providing simultaneous HDMI and
analog video sync processing. This allows for fast switching
between HDMI and the ADCs.
The ADV7604 supports the decoding of a component
RGB/YPrPb video signal into a digital YCrCb or RGB pixel
output stream. The support for component video includes 525i,
625i, 525p, 625p, 720p, 1080i, 1080p, and 1250i standards as
well as many other HD and SMPTE standards.
Graphics digitization is also supported by the ADV7604. The
ADV7604 is capable of digitizing RGB graphics signals from
VGA to UXGA rates and converting them into a digital RGB or
YCrCb pixel output stream.
The ADV7604 incorporates a quad input HDMI 1.3 compatible
receiver that supports all HDTV formats up to 1080p and
display resolutions up to UXGA (1600 × 1200 at 60 Hz). The
reception of encrypted video is possible with the inclusion of
HDCP. The HDMI receiver also includes
programmable/adaptive equalization that ensures robust
operation of the interface with cable lengths up to 30 meters.
The HDMI receiver has advanced audio functionality, such as a
mute controller that prevents audible extraneous noise in the
audio output.
Fabricated in an advanced CMOS process, the ADV7604 is
provided in a space-saving, 260-ball 15mm x 15mm BGA
surface-mount, Pb-free package and is specified over the −40°C
to +85°C temperature range.
