AVR 70 control board parts list
REF NO. Q'TY PART NO.
PCB P.C.B TOTAL ASSY CNT 1 7025-HK112-101-5
PCB P.C.B SUB ASSY CNT 1 7028-07210-101-0
PCB P.C.B CNT 1 7020-07210-000-0S
PCB P.C.B INS ASSY CNT-AXIAL 1 7027-07210-1A1-0
PCB P.C.B INS ASSY CNT-MANUAL 1 7027-07210-1M1-0
PCB P.C.B INS ASSY CNT-RADIAL 1 7027-07210-1R1-0
PCB P.C.B INS ASSY CNT-SMD 1 7027-07210-1S1-0
CN101/CN102 CN,WAFER C125Z1-19 19P BtoB HEADER(MALE) P=1.25MM 2 L109-01251-191-0S
CN105/CN106 CN,WAFER C125Z2-19 19P BtoB SOCKET(FEMALE) P=1.25MM 2 L109-01252-191-0S
CN100 CN,WAFER C125Z1-25 25P BtoB HEADER(MALE) P=1.25MM 1 L109-01251-251-0S
CN104 CN,WAFER C125Z2-25 25P BtoB SOCKET(FEMALE) P=1.25MM 1 L109-01252-251-0S
C653/C667 C,ELECT GE 85C 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) 2 D040-01008-715-0S
C678/C683 C,ELECT GE 85C 10UF-M/16V,3*5-5RE SY 2 D040-10008-305-0S
C650/C652 C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY 2 D040-10008-707-0S
C647 C,CERAMIC CHIP T.C X7R 0.01UF-K/50V-1608REEL 1 D010-10377-716-0S
C665/C668/C669 C,CERAMIC CHIP T.C X7R 0.01UF-K/50V-1608REEL 3 D010-10377-716-0S
C680/C682 C,CERAMIC CHIP T.C X7R 0.01UF-K/50V-1608REEL 2 D010-10377-716-0S
C672/C679/C681/C684 C,CERAMIC CHIP T.C COG33PF-J/50V-1608REEL 4 D010-33016-716-0S
C658 C,CERAMIC CHIP T.C COG 680pF-J 50V-1608REEL 1 D010-68116-716-0S
C657 C,CERAMIC CHIP HIK X7R3300PF-K/50V-1608REEL 1 D011-33277-716-0S
D566/D567 D,SWITCHING CHIP 1N4148WS FAST SWITCHING DOIDE Trr=4ns SOD-323 2 K005-04148-323-0S
IC558/IC560/IC561 IC,LINEAR OP UTC4580E SOP8 DUAL OP AMP 3 J121-45800-101-0S
Q583 SEMI,CHIP TR/PNP 2SA RT1P141C 0.2W/SC-59 ISAHAYA 1 J520-10141-121-0S
Q580 SEMI,CHIP TR/NPN 2SC RT1N441C 0.2W/SC-59 ISAHAYA 1 J522-10441-121-0S
Q581/Q582 SEMI,FET/2SN 2SK492C N-CH FET SC-59 ISAHAYA 2 J544-04920-121-0S
R692/R702 R,CARBON FILM 10K-J,1/5W-52RE-AX 2 C000-01036-P52-0S
R676 R,CARBON FILM 100K-J,1/5W-52RE-AX 1 C000-01046-P52-0S
R707 R,CARBON FILM 2.2K-J,1/5W-52RE-AX 1 C000-02226-P52-0S
R705/R710 R,CARBON FILM 9.1K-J,1/5W-52RE-AX 2 C000-09126-P52-0S
R701/R703/R706/R709 R,CHIP THICK 10K-J,1/16W-1608REEL 4 C200-01036-M16-0S
R711/R712 R,CHIP THICK 10K-J,1/16W-1608REEL 2 C200-01036-M16-0S
R680 R,CHIP THICK 100K-J,1/16W-1608REEL 1 C200-01046-M16-0S
R669/R671 R,CHIP THICK 4.7K-J,1/16W-1608REEL 2 C200-04726-M16-0S
R708 R,CHIP THICK 470K-J,1/16W-1608REEL 1 C200-04746-M16-0S
R677 R,CHIP THICK 5.6K-J,1/16W-1608REEL 1 C200-05626-M16-0S
R689/R704 R,CHIP THICK 91K-J,1/16W-1608REEL 2 C200-09136-M16-0S
J107 R,CHIP THICK 0-J,1/8W-3216REEL 1 C200-00006-130-0S
R672 R,CHIP THICK 1K-J,1/16W-1608REEL 1 C200-01026-M16-0S
R679 R,CHIP THICK 1.8K-J,1/16W-1608REEL 1 C200-01826-M16-0S
J101-J104/J106 CN,WIRE 1P JUMPER (0.6/52MM) 5 L045-08400-604-0S
PCB P.C.B SUB ASSY AVR700(HARMAN)/CNT2 1 7028-07210-201-0
PCB P.C.B INS ASSY AVR700(HARMAN)/CNT2-MANUAL 1 7027-07210-2M1-0
CN103 CN.WAFER C125Z1-29 29P BtoB HEADER(MALE) P=1.25MM 1 L109-01251-291-0S
CN107 CN.WAFER C125Z2-29 29P BtoB SOCKET(FEMALE) P=1.25MM 1 L109-01252-291-0S
AVR 70 front board parts list
REF NO. Q'TY PART NO.
PCB P.C.B TOTAL ASSY FRONT 1 7025-HK112-101-3
PCB P.C.B SUB ASSY FRONT 1 7028-06685-501-0
PCB P.C.B AVR133(HARMAN) 330*247 1.6T FR1 ARRY(2)/FRONT 1 7020-06685-000-2S
PCB P.C.B INS ASSY FRONT-AXIAL 1 7027-06685-5A1-0
PCB P.C.B INS ASSY FRONT-MANUAL 1 7027-06685-5M1-0
PCB P.C.B INS ASSY FRONT-RADIAL 1 7027-06685-5R1-0
PCB P.C.B INS ASSY FRONT-SMD 1 7027-06685-5S1-0
CB701-CB704 COIL,BEAD CBW160808U121T 120ohm SMD1608 TYPE 4 D340-16081-121-0S
L702 COIL,FILTER-INDUCTOR 10UH-Q40/24M-R2.5-52RE 02TB 1 D330-10070-052-0S
L700 COIL,FILTER-INDUCTOR 100UH-Q40/9M-R12-52RE 02TB 1 D330-10100-102-0S
L703/L704 COIL,FILTER-INDUCTOR 2.2UH-Q50/110M-R1.2 52RE-AXIAL LAL03TB 2 D330-2R200-052-0S
C707/C710 C,FILM POLYESTER ST-0.047UF-J/100V-5RE 2 D02047306C060S
C708/C709/C731 C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY 3 D040-10008-707-0S
C735L/R C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY 2 D040-10008-707-0S
C721 C,ELECT GE 85C 100UF-M/10V,5*11-5RE.SMS SY 1 D040-10108-207-0S
C703/C717 C,ELECT GE 85C 47UF-M/16V,5*7-5RE SRA SY 2 D040-47008-306-0S
C728 C,CERAMIC HIK AXIAL UP025 B103K-B-BZ 1 D005-10377-353-1S
C743-C745 C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL 3 D010-10116-716-0S
C734/C726/C727 C,CERAMIC CHIP T.C X7R 0.01UF-K/50V-1608REEL 3 D010-10377-716-0S
C718/C719 C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL 2 D011-10457-716-0S
C714-716 C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL 3 D011-10457-716-0S
C713L/R C,CERAMIC CHIP HIK X7R470PF-K/50V-1608REEL 2 D011-47176-716-0S
C704-C706 C,CERAMIC CHIP HIK X7R820PF-K/50V-1608REEL 3 D011-82177-716-0S
DESCRIPTION
