AVR 70 HDMI board parts list
REF NO. Q'TY PART NO.
PCB P.C.B TOTAL ASSY HDMI 1 7025-HK112-101-1
PCB P.C.B SUB ASSY HDMI 1 7028-07208-301-0
PCB P.C.B HDMI 1 7020-07208-020-0
PCB P.C.B INS ASSY HDMI-MANUAL 1 7027-07208-3M1-0
PCB P.C.B INS ASSY HDMI-SMD 1 7027-07208-3S1-0
L100-L114 COIL,BEAD 220ohm 15 D340-20120-221-0S
L117-119 COIL,BEAD 220ohm 3 D340-20120-221-0S
L124/L129/L131/L133 COIL,BEAD 220ohm 4 D340-20120-221-0S
L136/L137/L139/L140 COIL,BEAD 220ohm 4 D340-20120-221-0S
L142-L144 COIL,BEAD 220ohm 3 D340-20120-221-0S
L200-L206/L215 COIL,BEAD 120ohm 8 D340-16081-121-0S
L122/L125/L132/L134 COIL,INDUCTOR LB C2012T4R7M 4.7UH INDUCTOR 4 D310-4R701-020-0S
L135 COIL,CHIP DLP11SN121SL2L CHIP COMMON MODE CHOKE COIL 1 D311-12101-121-0S
L128/L130 COIL,CHIP FI-B1608-222KJT 2.2UH SMD(1608)-REEL 2 D311-16080-222-0S
L141 COIL,BEAD BKP2125 HS101-T 100ohm SMD2125 TYPE BEAD FOR POWER 1 D340-21256-101-0S
C269/C286/C348 C,CERAMIC CHIP HIK COG)10PF-D/50V-1005REEL 3 D011-10011-710-1S
C213/C215/C249 C,CERAMIC CHIP HIK COG)100PF-J/50V-1005REEL 3 D011-10116-710-1S
C102/C143/C235/C237 C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1005REEL 4 D011-10217-710-1S
C243/C245/C252/C257 C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1005REEL 4 D011-10217-710-1S
C260/C264/C266/C270 C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1005REEL 4 D011-10217-710-1S
C271/C276/C278/C280 C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1005REEL 4 D011-10217-710-1S
C287/C293/C299 C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1005REEL 3 D011-10217-710-1S
C307/C310/C325/C329 C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1005REEL 4 D011-10217-710-1S
C347/C349/C352 C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1005REEL 3 D011-10217-710-1S
C361-C365/C380 C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1005REEL 6 D011-10217-710-1S
C145/C149/C152 C,CERAMIC CHIP HIK X7R)0.01UF-K/16V-1005REEL 3 D011-10317-710-1S
C161/C164/C169 C,CERAMIC CHIP HIK X7R)0.01UF-K/16V-1005REEL 3 D011-10317-710-1S
C175/C177/C185/C187 C,CERAMIC CHIP HIK X7R)0.01UF-K/16V-1005REEL 4 D011-10317-710-1S
C192/C195/C206/C209 C,CERAMIC CHIP HIK X7R)0.01UF-K/16V-1005REEL 4 D011-10317-710-1S
C214/C218/C220/C226 C,CERAMIC CHIP HIK X7R)0.01UF-K/16V-1005REEL 4 D011-10317-710-1S
C227/C229/C231/C313 C,CERAMIC CHIP HIK X7R)0.01UF-K/16V-1005REEL 4 D011-10317-710-1S
C340/C343/C346 C,CERAMIC CHIP HIK X7R)0.01UF-K/16V-1005REEL 3 D011-10317-710-1S
C355/C357/C359 C,CERAMIC CHIP HIK X7R)0.01UF-K/16V-1005REEL 3 D011-10317-710-1S
C368/C369 C,CERAMIC CHIP HIK X7R)0.01UF-K/16V-1005REEL 2 D011-10317-710-1S
C104-C107 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 1 D011-10417-710-1S
C109/C111-C114 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 1 D011-10417-710-1S
C116/C117 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 1 D011-10417-710-1S
C120-C126 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 7 D011-10417-710-1S
C128/C130 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 2 D011-10417-710-1S
C132-C137 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 6 D011-10417-710-1S
C139/C141 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 2 D011-10417-710-1S
C146-C148 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 3 D011-10417-710-1S
C150/C154/C155/C157 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 4 D011-10417-710-1S
C159/C160/C166 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 3 D011-10417-710-1S
C182/C189/C199 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 3 D011-10417-710-1S
C201/C216/C225/C228 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 4 D011-10417-710-1S
C236/C244/C248/C250 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 4 D011-10417-710-1S
C253-C256 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 4 D011-10417-710-1S
C258/C259/C261/C262 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 4 D011-10417-710-1S
C265/C267/C268 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 3 D011-10417-710-1S
C273-C275 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 3 D011-10417-710-1S
C279/C281/C282 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 3 D011-10417-710-1S
C285/C288-C290 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 4
D011-10417-710-1S
C295-C297 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 3 D011-10417-710-1S
C300-C306 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 7 D011-10417-710-1S
C308/C309/C314 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 3 D011-10417-710-1S
C316/C317/C319 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 3 D011-10417-710-1S
C321-C323 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 3 D011-10417-710-1S
C326-C328 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 3 D011-10417-710-1S
C330/C332/C333 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 3 D011-10417-710-1S
C335/C337-C339 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 4 D011-10417-710-1S
C353/C377-C379 C,CERAMIC CHIP HIK X7R)0.1UF-K/16V-1005REEL 4 D011-10417-710-1S
C158 C,CERAMIC CHIP HIK X7R)1UF-K/16V-1608REEL 1 D011-10517-316-1S
C188/C190/C205/C263/C284 C,CERAMIC CHIP HIK X5R)10UF-K/10V-2012REEL GRM21BR61A106KE19L 5 D011-10657-220-0S
C101/C103/C165/C167 C,CERAMIC CHIP HIK COG)15PF-J/50V-1005REEL 4 D011-15016-710-1S
C292/C294 C,CERAMIC CHIP HIK COG)18PF-J/50V-1005REEL 2 D011-18016-710-1S
C351 C,CERAMIC CHIP HIK COG)20PF-J/50V-1005REEL 1 D011-20016-710-1S
C171/C179/C184/C186 C,CERAMIC CHIP HIK COG)22PF-J/50V-1005REEL 4 D011-22016-710-1S
C207/C208/C350 C,CERAMIC CHIP HIK COG)22PF-J/50V-1005REEL 3 D011-22016-710-1S
C272/C311 C,CERAMIC CHIP HIK X7R)0.22UF-K/25V-1608REEL TDK 2 D011-22477-416-2S
C174/C196/C197 C,CERAMIC CHIP HIK COG)330PF-J/50V-1005REEL 3 D011-33116-710-1S
C200/C204/C251 C,CERAMIC CHIP HIK COG)330PF-J/50V-1005REEL 3 D011-33116-710-1S
C291/C298 C,CERAMIC CHIP HIK COG)330PF-J/50V-1005REEL 2 D011-33116-710-1S
C303/C318/C331/C342 C,CERAMIC CHIP HIK COG)330PF-J/50V-1005REEL 4 D011-33116-710-1S
C172/C173 C,CERAMIC CHIP HIK COG)47PF-J/50V-1005REEL 2 D011-47016-710-1S
C108/C127/C163/C238 C,ELECT CHIP(GE) 1UF-MVG/50V,4.3*5.1*5.3 REEL (Z8155) SY 4 D050-01008-720-0S
DESCRIPTION
COILS
CAPACITOR
