User Guide — EPF011C_UG
Confidential Proprietary
NON-DISCLOSURE AGREEMENT REQUIRED
6
2.3 Pin Description
Unless otherwise stated, unused input pins must be tied to ground, and unused output pins left open.
Table 2-1 Pin Description
Name In/Out Buffer Type Description
OP_MODE IN IXDXXP
Chip operation mode.
0: Normal mode
1: ICP (In Circuit Flash Programming) mode
NOTE: The input crystal rate will be 24MHz if this ICP mode is used.
RSTb IN BDUX8P
External Reset (active low) with on-chip pull-up. When this pin is asserted
low, the chip is totally reset.
X_IN IN XTL24P crystal input
X_OUT OUT XTL24P crystal output
P0[2:0] IN/OUT BRXX12P GPIO port 0 with programmable Open Drain capability.
P11 IN/OUT BRUX8P
GPIO port 1 or Keyboard Interrupt inputs with internal 20K: pull-up to
VDD
P21 IN/OUT BRXX8P GPIO port 2 with programmable Open Drain capability.
P3[5:4, 1:0] OD IN/OUT BRXX8P Open Drain I/O port 3. Shared with IIC.
P41 IN/OUT BRXX8P GPIO port 4 or External Interrupt inputs
P50 IN/OUT BRXX24P GPIO port 5 with programmable Open Drain capability. 20 mA drive
P7[4,1:0] IN/OUT BRXX8P
Open Drain I/O port 7. P7[1:0] shared with Serial Port. P7[4] share with
CIR.
P87 IN/OUT BRXX8P GPIO port 8 with programmable Open Drain capability. Share with PWM
P90 IN/OUT BRXX8P GPIO port 9 with programmable Open Drain capability.
VDD PWR - Digital VDD (3.3V)
VSS PWR - Digital Ground
