AVR 70 main board parts list
REF NO. Q'TY PART NO.
C264 C,ELECT GE 85C 100UF-M/16V,6.3*11-5RE,SMS SY 1 D040-10108-307-0S
C167 C,ELECT GE 85C 2.2UF-M/50V,5*11-5RE SMS SY (Pb Free) 1 D040-2R208-716-0S
C193/C195 C,ELECT GE 85C 330UF-M/10V,6.3*11-5RE,SHL-SY 2 D040-33108-207-0S
C131/C139 C,ELECT GE 85C 47UF-M/16V,5*11-5RE.SMS SY 2 D040-47008-308-0S
C145SW/C146SW C,ELECT GE 85C 47UF-M/16V,5*11-5RE.SMS SY 2 D040-47008-308-0S
C252/C254 C,ELECT GE 85C 47UF-M/16V,5*11-5RE.SMS SY 2 D040-47008-308-0S
C257/C258 C,ELECT GE 85C 470UF-M/10V,6.3*11-5RE,SHL SY 2 D040-47108-206-0S
C158C/L/R/SL/SR C,ELECT GE 85C 4.7UF-M/50V,5*11-5RE.SMS SY 5 D040-4R708-725-0S
C219/C222/C223 C,ELECT GE 85C 4.7UF-M/50V,5*11-5RE.SMS SY 3 D040-4R708-725-0S
C190 C,ELECT GE 85C 4.7UF-M/100V,5*11-5RE.SMS SY 1 D040-4R708-C06-0S
C179/C180 C,ELECT GE 85C 10000UF-M/63V,30*50 DL-BLK SY 2 D040103088380S
C189 C,ELECT GE 85C 330UF-M/63V,12.5*20 SY 1 D040331088230S
C207 C,ELECT GE 85C 2200UF-M/25V,12.5*25 SHL SY 1 D040-22208-400-0S
C206 C,ELECT GE 85C 4700UF-M/25V,16*31.5L.BLK SY 1 D040472084020S
C200 C,ELECT GE 85C SHL 10000UF 16V M 18*35 P=7.5MM SY 1 D040-10308-302-0S
C1254 C,CERAMIC CHIP T.C COG10PF-D/50V-1608REEL 1 D010-10011-716-0S
C1261/1266/C1267 C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL 3 D010-10116-716-0S
C137/C138 C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL 2 D010-10116-716-0S
C164SW C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL 1 D010-10116-716-0S
C615/C617/C618 C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL 3 D010-10116-716-0S
C621 C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL 1 D010-10116-716-0S
C1234/C1253 C,CERAMIC CHIP T.C X7R 0.01UF-K/50V-1608REEL 2 D010-10377-716-0S
C1259/C1260 C,CERAMIC CHIP T.C X7R 0.01UF-K/50V-1608REEL 2 D010-10377-716-0S
C135/C1366 C,CERAMIC CHIP T.C X7R 0.01UF-K/50V-1608REEL 2 D010-10377-716-0S
C141SW/C144SW C,CERAMIC CHIP T.C X7R 0.01UF-K/50V-1608REEL 2 D010-10377-716-0S
C159C/F/S/SW C,CERAMIC CHIP T.C X7R 0.01UF-K/50V-1608REEL 1 D010-10377-716-0S
C168C/169 C,CERAMIC CHIP T.C X7R 0.01UF-K/50V-1608REEL 4 D010-10377-716-0S
C231-C234 C,CERAMIC CHIP T.C X7R 0.01UF-K/50V-1608REEL 4 D010-10377-716-0S
C467/C468 C,CERAMIC CHIP T.C X7R 0.01UF-K/50V-1608REEL 2 D010-10377-716-0S
C1258/C1269 C,CERAMIC CHIP T.C COG15PF-J/50V-1608REEL 2 D010-15016-716-0S
C105L/R C,CERAMIC CHIP T.C COG220PF-J/50V-1608REEL 2 D010-22116-716-0S
C107L/R C,CERAMIC CHIP T.C COG220PF-J/50V-1608REEL 2 D010-22116-716-0S
C109L/R C,CERAMIC CHIP T.C COG220PF-J/50V-1608REEL 2 D010-22116-716-0S
C111L/R C,CERAMIC CHIP T.C COG220PF-J/50V-1608REEL 2 D010-22116-716-0S
C251/C253 C,CERAMIC CHIP T.C COG220PF-J/50V-1608REEL 2 D010-22116-716-0S
C1265/C1268 C,CERAMIC CHIP T.C COG24PF-J/50V-1608REEL 2 D010-24016-716-0S
C143SW C,CERAMIC CHIP T.C COG47PF-J/50V-1608REEL 1 D010-47016-716-0S
C142SW C,CERAMIC CHIP HIK X7R1000PF-K/50V-1608REEL 1 D011-10277-716-0S
C1257 C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL 1 D011-10457-716-0S
C192/C194/C196 C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL 3 D011-10457-716-0S
C227/C228 C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL 2 D011-10457-716-0S
C414/C685 C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL 2 D011-10457-716-0S
C122/C132 C,CERAMIC CHIP HIK Y5V 0.15uF-Z/10V-1608REEL 2 D011-15479-216-0S
C120/C134 C,CERAMIC CHIP HIK X7R0.022UF-K/25V-1608REEL 2 D011-22377-716-0S
C121/C133/C260 C,CERAMIC CHIP HIK X7R0.047UF-K/16V-1608REEL 3 D011-47377-316-0S
C229 C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL 1 D011-10457-716-0S
C1271 C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL 1 D010-10116-716-0S
C206R/L C,CERAMIC CHIP HIK X7R4700PF-K/50V-1608REEL 2 D011-47277-716-0S
C205R1/L C,CERAMIC CHIP HIK X7R4700PF-K/50V-1608REEL 2 D011-47277-716-0S
C419/C420/C422 C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL 3 D011-10457-716-0S
C423 C,CERAMIC CHIP HIK X7R1000PF-K/50V-1608REEL 1 D011-10277-716-0S
C322 C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL 1 D011-10457-716-0S
CP102 CN.WAFER 2.5MM 5267-06A 6P 1
L102526700600S
CP111 CN.WAFER 2.5MM 5267-12A 12P 1 L102-52670-120-0S
CP101 CN.WAFER 7.92MM 35328-0360, 7.92MM HEADER,VER,3CKT 1 L108-35328-036-0S
CN101/CN107 CN,WAFER C125Z1-19 19P BtoB HEADER(MALE) P=1.25MM 2 L109-01251-191-0S
CN106 CN.WAFER C125Z1-29 29P BtoB HEADER(MALE) P=1.25MM 1 L109-01251-291-0S
FPC103/FPC104 CN.FPC 1.0MM 1.0-11S-10PW 10P AN DIP TOP CONTACT 2 L130-10011-105-0S
CP103 CN.FPC 1.25MM 127301107K2 BLK ST 7P 1 L131007100010S
CP117 CN.WAFER 2.0MM 20010WS-02A00 DIP2P STRAIGHT 1 L101-20010-021-0S
CP116 CN.WAFER 2.0MM 20010WS-04A00 DIP4P STRAIGHT 1 L101-20010-041-0S
CP104 CN.WAFER 2.0MM 20010WS-05A00 DIP5P STRAIGHT 1 L101-20010-051-0S
CP112 CN.WAFER 2.0MM 20010WS-10A00 DIP10P STRAIGHT 1 L101200101010S
CN105 CN,WAFER C125Z1-25 25P BtoB HEADER(MALE) P=1.25MM 1 L109-01251-251-0S
D101-D110 D,SWITCHING CHIP 1N4148WS FAST SWITCHING DOIDE Trr=4ns SOD-323 10 K005-04148-323-0S
D126-D128 D,SWITCHING CHIP 1N4148WS FAST SWITCHING DOIDE Trr=4ns SOD-323 3 K005-04148-323-0S
D120/D121/D123 D,SWITCHING CHIP 1N4148WS FAST SWITCHING DOIDE Trr=4ns SOD-323 3 K005-04148-323-0S
D142/D139 D,SWITCHING CHIP 1N4148WS FAST SWITCHING DOIDE Trr=4ns SOD-323 2 K005-04148-323-0S
D201/D202 D,SWITCHING CHIP 1N4148WS FAST SWITCHING DOIDE Trr=4ns SOD-323 2 K005-04148-323-0S
D116-D119 D,SWITCHING 1SS133T-72-52MM 4 K000013300520S
D124 D,SWITCHING 1SS133T-72-52MM 1 K000013300520S
D122 D,SWITCHING 1N4007 52REEL 1000V 1A 1 K000-40070-001-0S
D129-D134 D,SWITCHING 1N4007 52REEL 1000V 1A 6 K000-40070-001-0S
ZD109 D,ZENER CHIP 0.2W 5.1V UDZ S SERIES (UMD2 TYPE) 1 K06605R14P400S
ZD105/ZD107 D,ZENER CHIP 0.2W 3.3V UDZ S SERIES (UMD2 TYPE) 2 K06603R34P400S
ZD101/ZD102 D,ZENER CHIP 0.2W 7.5V UDZ S SERIES (UMD2 TYPE) 2 K06607R54P400S
ZD103/ZD104 D,ZENER CHIP 0.2W 16V UDZ S SERIES (UMD2 TYPE) 1 K06616R04P400S
