AVR 70 HDMI board parts list
REF NO. Q'TY PART NO.
R148/R314 R,CHIP THICK 470-J , 1/16W 2 C200-04716-M10-1S
R207/R211/R244/R245 R,CHIP THICK 4.7K-J , 1/16W 4 C200-04726-M10-1S
R248/R250/R267/R271 R,CHIP THICK 4.7K-J , 1/16W 4 C200-04726-M10-1S
R376/R377/R483/R484 R,CHIP THICK 4.7K-J , 1/16W 3 C200-04726-M10-1S
R513/R525 R,CHIP THICK 4.7K-J , 1/16W 2 C200-04726-M10-1S
R102/R131/R154/R187 R,CHIP THICK 47K-J , 1/16W 4 C200-04736-M10-1S
R196/R198/R249/R261 R,CHIP THICK 47K-J , 1/16W 4 C200-04736-M10-1S
R274/R299/R317/R330 R,CHIP THICK 47K-J , 1/16W 4 C200-04736-M10-1S
R372/R380/R408/R439 R,CHIP THICK 47K-J , 1/16W 4 C200-04736-M10-1S
R477/R478/R552 R,CHIP THICK 47K-J , 1/16W 3 C200-04736-M10-1S
R205/R528 R,CHIP THICK 47K-J , 1/16W 2 C200-04736-M10-1S
R506-R510 R,CHIP THICK 470K-J , 1/16W 5 C200-04746-M10-1S
R182/R183 R,CHIP THICK 51-J , 1/16W 2 C200-05106-M10-1S
R440 R,CHIP THICK 51K-J , 1/16W 1 C200-05136-M10-1S
R113-R115 R,CHIP THICK 5.6-J , 1/16W 3 C200-5R606-M10-1S
R118/R119 R,CHIP THICK 5.6-J , 1/16W 2 C200-5R606-M10-1S
R121/R122/R124/R124 R,CHIP THICK 5.6-J , 1/16W 4 C200-5R606-M10-1S
R142-R144 R,CHIP THICK 5.6-J , 1/16W 3 C200-5R606-M10-1S
R146/R147 R,CHIP THICK 5.6-J , 1/16W 2 C200-5R606-M10-1S
R149-R151 R,CHIP THICK 5.6-J , 1/16W 3 C200-5R606-M10-1S
R167/R171/R175 R,CHIP THICK 5.6-J , 1/16W 3 C200-5R606-M10-1S
R177/R178 R,CHIP THICK 5.6-J , 1/16W 2 C200-5R606-M10-1S
R180/R181/R186 R,CHIP THICK 5.6-J , 1/16W 3 C200-5R606-M10-1S
R234/R235/R240/R241 R,CHIP THICK 56-J , 1/16W 4 C200-05606-M10-1S
R334 R,CHIP THICK 56-J , 1/16W 1 C200-05606-M10-1S
R112/R141/R165 R,CHIP THICK 5.6K-J , 1/16W 3 C200-05626-M10-1S
R561 R,CHIP THICK 68K-J , 1/16W 1 C200-06836-M10-1S
R480 R,CHIP THICK 680K-J , 1/16W 1 C200-06846-M10-1S
R218 R,CHIP THICK 75-J , 1/16W 1 C200-07506-M10-1S
R560 R,CHIP THICK 75K-J , 1/16W 1 C200-07536-M10-1S
XTAL105 CRYSTAL CHIP FCX-04(16MHz) CL=7PF SMD3225 RIVER 1 E805-16R00-008-0S
XTAL100 CRYSTAL CHIP 18.432MHz CL=15PF HCX-5FA/SMD5032 1 E805-18R43-201-0S
XTAL101/XTAL104 CRYSTAL CHIP 24.000MHz CL=15PF HCX-5FA/SMD5032 2 E805-24R00-004-0S
XTAL102 CRYSTAL CHIP FCX-04(24.576MHz) CL=10PF SMD3225 RIVER 1 E805-24R57-608-0S
IC104/IC110 IC,LINEAR-REGULATOR IL1117-3.3 SOT-223 3.3V 1A LOW DROPOUT 2 J126111700041S
IC102/IC114 IC,LINEAR-REGULATOR IL1117_1.8 SOT-223 1.8V 1A LOW DROPOUT 2 J126-11171-001-1S
IC111 IC,LINEAR-REGULATOR IL1117_1.2 SOT-223 1.2V 1A LOW DROPOUT 1 J126111712040S
AVR 70 main board parts list
REF NO. Q'TY PART NO.
PCB P.C.B TOTAL ASSY MAIN 1 7025-HK112-101-0
PCB P.C.B SUB ASSY MAIN 1 7028-07209-101-0
PCB P.C.B MAIN 1 7020-07209-000-0S
PCB P.C.B INS ASSY MAIN-AXIAL 1 7027-07209-1A1-0
PCB P.C.B INS ASSY MAIN-MANUAL 1 7027-07209-1M1-0
PCB P.C.B INS ASSY MAIN-RADIAL 1 7027-07209-1R1-0
PCB P.C.B INS ASSY MAIN-SMD 1 7027-07209-1S1-0
BD101/BD103/BD104 COIL,BEAD 120ohm 3 D340-16081-121-0S
BD106-BD110 COIL,BEAD 120ohm 5 D340-16081-121-0S
BD120 COIL,BEAD 120ohm 1 D340-16081-121-0S
L1201 COIL,FILTER-INDUCTOR 33UH-Q40/14M-R4.7-52RE 1 D330-33070-052-0S
C207R/L C,ELECT GE 85C 4.7UF-M/50V,5*11-5RE.SMS SY 2 D040-4R708-725-0S
C170/C171 C,ELECT GE 85C 4.7UF-M/50V,5*11-5RE.SMS SY 2 D040-4R708-725-0S
C212/C213 C,ELECT GE 85C 10UF-M/16V,5*11-5RE.SHL SY 2 D040-10008-310-0S
C356/C357 C,CERAMIC SEMI DISC F0.1UF-Z/50V-5RE PI6 2 D006-10459-705-0S
C161C/L/R/SL/SR C,FILM POLYESTER ST-0.01UF-J/100V-5RE PEFAM103J100 PEF TYPE 5 D02010306C060S
C162C/L/R/SL/SR C,FILM POLYESTER ST-0.01UF-J/100V-5RE PEFAM103J100 PEF TYPE 5 D020-10306-C06-0S
C160C/L/R/SL/SR C,FILM POLYESTER ST-0.1UF-J/100V-5RE PEFAM104J100 PEF TYPE 5 D020-10306-C06-0S
C201-C203 C,FILM POLYESTER ST-0.1UF-J/100V-5RE PEFAM104J100 PEF TYPE 3 D020-10306-C06-0S
C208-C210 C,FILM POLYESTER ST-0.1UF-J/100V-5RE PEFAM104J100 PEF TYPE 3 D020-10306-C06-0S
C182-C186 C,FILM POLYESTER RED-0.1UF-K/250V-5RE PCMT365 5 D02010407H080S
C187/C188 C,ELECT GE 85C 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) 2 D040-01008-715-0S
C204/C205 C,ELECT GE 85C 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) 2 D040-01008-715-0S
C604/C608/C620 C,ELECT GE 85C 10UF-M/16V,5*11-5RE.SHL SY 3 D040-10008-310-0S
C623 C,ELECT GE 85C 10UF-M/16V,5*11-5RE.SHL SY 1 D040-10008-310-0S
C106L/R C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY 2 D040-10008-707-0S
C108L/R C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY 2 D040-10008-707-0S
C110L/R C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY 2 D040-10008-707-0S
C112L/R C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY 2 D040-10008-707-0S
C140SW C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY 1 D040-10008-707-0S
C158SW C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY 1 D040-10008-707-0S
C176/C178 C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY 2 D040-10008-707-0S
C191 C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY 1 D040-10008-707-0S
C123-C128 C,ELECT GE 85C 100UF-M/10V,5*11-5RE.SMS SY 6 D040-10108-209-0S
C197 C,ELECT GE 85C 100UF-M/10V,5*11-5RE.SMS SY 1 D040-10108-209-0S
C1235/C1263/C1270 C,ELECT GE 85C 100UF-M/16V,6.3*11-5RE,SMS SY 3 D040-10108-307-0S
ETC
COILS
CAPACITOR
DESCRIPTION
To Next Page
