AVR 70 HDMI board parts list
REF NO. Q'TY PART NO.
C110/C118/C129/C131 C,ELECT CHIP(GE) 10UF-MVG/16V,3.3*3.7*5.2 REEL (Z8154) SY 4 D050-10008-347-0S
C180/C232/C356/C360 C,ELECT CHIP(GE) 10UF-MVG/16V,3.3*3.7*5.2 REEL (Z8154) SY 4 D050-10008-347-0S
C370-C374 C,ELECT CHIP(GE) 10UF-MVG/16V,3.3*3.7*5.2 REEL (Z8154) SY 5 D050-10008-347-0S
C162/C191/C193/C198 C,ELECT CHIP(GE) 100UF-MVG/6.3V,5.3*5.9*5.3 3REEL (Z8156) SY 4 D050101081650S
C203/C277/C312/C324/C354 C,ELECT CHIP(GE) 100UF-MVG/6.3V,5.3*5.9*5.3 3REEL (Z8156) SY 5 D050101081650S
C210/C230/C241/C246 C,ELECT CHIP(GE) 220UF-M/6.3V,6.6*7.2*5.7 REEL (Z8157) (F55) SY 4 D050221081200S
C358/C382 C,ELECT CHIP(GE) 220UF-M/6.3V,6.6*7.2*5.7 REEL (Z8157) (F55) SY 2 D050221081200S
C144/C153/C240 C,ELECT CHIP(GE) 220UF-M/6.3V,6.6*7.2*5.7 REEL (Z8157) (F55) SY 1 D050221081200S
C100 C,ELECT CHIP(GE) 2.2UF-MVG/50V,3.3*3.7*5.2 REEL (Z8154) SY 1 D0502R2083200S
C119/C140/C142 C,ELECT CHIP(GE) 47UF-MVG/16V,5.3*5.9*5.3 REEL (Z8156) SY 3 D050470083200S
C151/C156/C168 C,ELECT CHIP(GE) 47UF-MVG/16V,5.3*5.9*5.3 REEL (Z8156) SY 3 D050470083200S
C176/C217/C219 C,ELECT CHIP(GE) 47UF-MVG/16V,5.3*5.9*5.3 REEL (Z8156) SY 3 D050470083200S
C183 C,ELECT CHIP(GE) 0.1UF-MVG/50V,3.3*3.7*5.2 REEL (Z8154) SY 1 D050R10080010S
C500 C,CERAMIC CHIP HIK X7R)0.22UF-K/25V-1608REEL TDK 1 D011224774162S
C221/C222 C,CERAMIC CHIP HIK COG)20PF-J/50V-1005REEL 2 D011200167101S
C202 C,CERAMIC CHIP HIK X7R2200PF-K/50V-1608REEL 1 D011222777160S
CP100 CN.WAFER 2.0MM 20022WS-04C 4P STRAIGHT SMT 1 L101200220410S
CN102-CN104 CN,WAFER C125Z2-19 19P BtoB SOCKET(FEMALE) P=1.25MM 3 L109-01252-191-0S
CN105 CN,WAFER C125Z2-25 25P BtoB SOCKET(FEMALE) P=1.25MM 1 L109-01252-251-0S
JACK100-JACK103 CN.WAFER AD3PBI19GO-REV_B 3ROW 19P DIP HDMICON R/A W/FLANGE 4 L109-10019-016-0S
FPC100 CN.FPC 1.25MM 1.25-9-17PB 17P VERTICAL SMT 1 L131-12509-173-0S
CP100 CN.WAFER 2.0MM 20022WS-04C 4P STRAIGHT SMT 1 L101-20022-041-0S
D137-D139/D153 D,ZENER CHIP 0.2W 5.1V UDZ S SERIES (UMD2 TYPE) 4 K06605R14P400S
ZD106 D,ZENER CHIP 0.2W 2.4V UDZS B SERIES (UMD2 TYPE) 1 K066-02R44-P40-0S
D100-D136 D,ESD CHIP CDS2C05HDMI1 CERADIODE ESD FOR HDMI 1005REEL 37 K067-02050-00-10S
D140-D151 D,ESD CHIP CDS2C05HDMI1 CERADIODE ESD FOR HDMI 1005REEL 12 K067-02050-00-10S
C223/C224/R28/R269 D,ESD CHIP CDS2C05HDMI1 CERADIODE ESD FOR HDMI 1005REEL 4 K067-02050-00-10S
D155/D156 D,SCHOTTKY RB501V-40 VF=0.43V AT100MA SOD-323 2 K120-50100-001-0S
D152/D154 D,SWITCHING CHIP KDS4148U FAST SWITCHING SOD-323(USC) 2 K005041480030S
D157-D162 D,SWITCHING CHIP KDS4148U FAST SWITCHING SOD-323(USC) 6 K005041480030S
IC120 IC,MEMORY-EEPROM CW24C16DR/ADR 16Kbit 1.8V TO 5.5V SOP8P 1 J000-24160-017-0S
IC113 IC,MEMORY-RAM W9864G6JH-6 1M*4BANKS*16BIT(64MB) TSOP54 1 J001-98646-601-0S
IC119 IC,CPU MICRO PROCESS M3030RFGPFP FLASH(256K,12K)QFP100 1 J020-30302-004-0S
IC108 IC,LOGIC 74VHCU04MTCX HEX INVERTER TSSOP14P 1 J040-74040-027-0S
IC115 IC,LOGIC 74LCX257MTC TSSOP-16P QUAD 2-INPUT MULTIPLEXER 1 J040-74257-004-0S
IC100 IC,LOGIC-INTERFACE EP94A1 HDMI 1.3 4TO1 REPEATER LQFP128 1 J046-94100-001-0S
IC117 IC,ANALOG TMS320DA808K013BPTP400 DSP S-PQFP-G176 1 J080-32080-801-0S
IC106 IC,LINEAR-REGULATOR NJM2831F33 3.3V 0.13A LDO WITH ON/OFF SOT-23-5P 1 J126-28313-301-0S
IC105 IC,LINEAR-DRIVER EPF011C GENERIC MCU 64K EMBEDDED FLASH SSOP24 1 J127-01100-001-0S
IC103 IC,LINEAR-DRIVER EPF021A KEYBOARD CONTROLLER LQFP64 1 J127-02100-001-0S
IC116 IC,MEMORY FLASH W25Q32BVSSIG 32M-BIT SERIAL FLASH SOIC8 1 J005-25320-002-0S
IC123 IC,LOGIC-INTERFACE TPS2557DRB CURRENT LIMIT LOAD SW SON8 1 J046-25570-001-0S
IC109 IC,ANALOG AK4588 AUDIO CODEC WITH DIR LQFP80P (Pb Free) 1 J080458800010S
IC122 IC,LOGIC TC74VHC157FK-TBB VSSOP16 QUAD 2CH MULTIPLEXER 1 J040-74157-039-0S
JACK100-JACK103 CN.WAFER AD3PBI19GO-REV_B 3ROW 19P DIP HDMICON R/A W/FLANGE 4 L109-10019-016-0S
JACK104/JACK105 MODULE JSR1165/OPTICAL RECEIVER 96K SHUTTER 2 E100116500040S
JACK106 TER,RCA 1PIN RCA-107A0(ORANGE) 1 G600-107A0-001-YS
Q100/Q102/Q104/Q138 SEMI,CHIP TR/NPN 2SC KRC102S (NB) 0.2W/SOT-23 REEL 4 J522-01020-021-0S
Q107/Q111 SEMI,CHIP TR/NPN 2SC RT1N141C 0.2W/SC-59 ISAHAYA 2 J522-10141-121-0S
Q101/Q103/Q105 SEMI,CHIP TR/NPN 2SC KRC104S (ND)/SOT-23 REEL 3 J522-10141-121-0S
Q139 SEMI,CHIP TR/NPN 2SC KTC2875B(MB) 0.15W/LOW-ON-RES SOT23(RTK)-REEL 1 J522-2875B-001-0S
Q106/Q110 SEMI,FET CHIP FDC608PZ P-CH 2.5V MOSFET SOT6 2 J543-60800-001-0S
FU100 R,CHIP THICK 0-J , 1/10W 1
C200-00006-020-1S
R221/R260/R2626/R270 R,CHIP THICK 0-J , 1/10W 4 C200-00006-020-1S
R295/R389/R450 R,CHIP THICK 0-J , 1/10W 3 C200-00006-020-1S
L126/L127 R,CHIP THICK 0-J , 1/10W 2 C200-00006-020-1S
L138/C145 R,CHIP THICK 0-J , 1/10W 2 C200-00006-020-1S
R104 R,CHIP THICK 0-J , 1/16W 1 C200-00006-M10-1S
R1050/R1051 R,CHIP THICK 0-J , 1/16W 2 C200-00006-M10-1S
R243/R264/R265/R300 R,CHIP THICK 0-J , 1/16W 4 C200-00006-M10-1S
R336/R338/R340 R,CHIP THICK 0-J , 1/16W 3 C200-00006-M10-1S
R343/R344/R347 R,CHIP THICK 0-J , 1/16W 3 C200-00006-M10-1S
R381/R385/R395 R,CHIP THICK 0-J , 1/16W 3 C200-00006-M10-1S
R405/R406 R,CHIP THICK 0-J , 1/16W 2 C200-00006-M10-1S
R419 R,CHIP THICK 0-J , 1/16W 1 C200-00006-M10-1S
R123 R,CHIP THICK 0-J , 1/16W 1 C200-00006-M10-1S
R1052 R,CHIP THICK 0-J , 1/16W 1 C200-00006-M10-1S
R125-R128 R,CHIP THICK 0-J , 1/16W 4 C200-00006-M10-1S
RESISTOR
CONNECTOR
DIODES
INTEGRATED CIRCUITS
JACKS
TRANSIS
TOR
