APPENDIX 59
APPENDIX
System Defaults
The three tables in this section show the factory default settings for the Video Inputs, Video Sources and Video Display Aspect Ratios. These tables give you
the complete picture on the AVR 7300’s initial settings. You may then decide whether any item needs to be changed so that it is more appropriate for your
specific installation. Any of the settings shown may be changed as shown in the pages of the System Configuration section of this manual (pages 19–32).
Table 1: Video Input Defaults
INPUT AUDIO INPUT COMPONENT VIDEO INPUT INPUT SOURCE TYPE DISPLAY TYPE
Video 1 ANALOG COMPONENT VIDEO 1 VCR CRT
Video 2 ANALOG COMPONENT VIDEO 2 CABLE DIGITAL CRT
Video 3 OPTICAL 1 COMPONENT VIDEO 2 CABLE ANALOG CRT
Video 4 ANALOG COMPONENT VIDEO 2 SATELLITE DIGITAL CRT
Video 5 ANALOG COMPONENT VIDEO 2 CAMERA DIGITAL CRT
DVD COAXIAL 1 DVD COMPONENT VIDEO DVD CRT
Table 2: Video Source Defaults
Feature DVD VCR CABLE DIG SAT DIG SAT ANALOG CABLE ANALOG CAMERA DIG CAMERA ANALOG
Noise Reduction OFF ON OFF OFF ON ON OFF ON
X-Color Suppressor ON ON ON ON ON ON ON ON
DCDi Interpolation ON ON ON ON ON ON ON ON
Film Mode Detect ON ON ON ON ON ON ON ON
Film Mode Edit Detect ON ON ON ON ON ON ON ON
Composite Video Enhancement ON ON ON ON ON ON ON ON
VCR Sync Time Enhancement ON ON ON ON ON ON ON ON
Input Aspect Ratio 4:3 4:3 4:3 4:3 4:3 4:3 4:3 4:3
Table 3: Video Display Aspect Ratio Defaults
DISPLAY TYPE ASPECT RATIO
CRT 4:3
Projection 4:3
Plasma (PDP) 16:9
DLP 16:9
LCD 16:9
Personal Settings Worksheets
Once you have installed the AVR 7300 and found the combination of audio and video settings that works best in your system, we recommend that you
record them here to provide a written backup of your system’s configuration. These worksheets make it easy for you to reestablish your settings if the
internal memory is lost due to an extended power outage or reset due to a system upgrade, processor reset or other service to the unit.Additional copies of
these worksheets may be downloaded from the Harman Kardon Web site at (www.harmankardon.com/).
Worksheet 1: System Settings
FEATURE SETTING
Record Output
Video Display Type
Surround Back Amps
VFD Fade Time-Out
VFD
Volume Default
Default Volume Set
Semi-OSD Time-Out
Full-OSD Time-Out
Surround Back Amp Config
To Next Page
