Harman AKG DHT800 User Manual

eQuiPment descriPtion
DMS800 MANUAL
71
Digital True Diversity receiver DSR800
Bass roll off
2nd order shelving filter, selectable betw. 10–300Hz
Equalizer 3-band(amplicationorpaddingofthelows,
mids and highs)
Compressor dbx®(parameters:amplication,response
threshold, ratio, attack, release)
Limiter dbx® (parameter: usage threshold)
Transmitter battery indi‑
cator
7‑segments
PC interface
Ethernet via HUB4000 Q (optional)
Ethernet via Dante™ (100 Mbit/s)
Software HiQnet Audio Architect
Power supply 100 ‑ 240 V AC, 50 ‑ 60 Hz, 0.4 A
Dimensions
Standard housing for rack mounting, 1 RU
480(W)x45(H)x230(D) mm/ 189(W)x18(H)x91(D) in
Net weight
2.38 kg / 84 oz
Digital bodypack transmitter DPT800
Carrier frequency range
(country‑dependent)
Transmission power
Scatter ≤-70dBc
Antenna
λ/4 antenna
Audio input
3‑pol. Mini‑XLR socket (3.0
Vrms max.)
Audio input
gain
0 dB, +10 dB, +20 dB switchable
Operating time
typ.6
.5hours(2x1.5VLR6AAbatteries)
typ.6.5hours(2x1.2VAANiMH
rechargeablebatteries>2100mAh)
Dimensions
65(W)x28(
H)x82(D) mm/ 25.6(W)x11(H)x82.3(D) in
Net weight
88 g / 3.10 oz
without batteries
DSR800
DPT800
Band 1: 550.1 – 662.9 MHz
Band 2: 730.1 – 831.9 MHz
10, 20 mW (ERP max.), can be set via menu
(country-dependent)
