Harman AKG DHT800 - System Commissioning Procedures; Initial Setup and Antenna Connection

commissioning
DMS800 MANUAL
77
6 Commissioning
Before commissioning your DMS800, check that the transmitter and receiver
are set to the same frequency.
To commission the DMS800, proceed as follows:
1. Insert batteries into the transmitter
2. Connect the antennas
3. Position the receiver
4. Connectthereceivertothemixingconsole/amplier
5. Reposition the GROUND LIFT switch (optional)
6. Connect the receiver to the power network
6.1 Insert batteries into the transmitter
Step Description
1 Open the battery compartment cover (9)
2 Insert batteries into the battery compartment.
When inserting the batteries, note the symbols in the battery
compartment to ensure the power supply.
3 Close the battery compartment cover (9)
6.2 Connecting the antennas
The following antennas can be mounted on the receiver:
• λ/4 antennas (included as standard)
For all applications where there is a line of sight between the trans‑
mitter and receiver antennas.
• Remote antennas
For applications where the reception conditions are not optimal at
the receiver position.
