eQuiPment descriPtion
DMS800 MANUAL
72
Digital handheld transmitter DHT800
Carrier frequency range
(country‑dependent)
Transmission power
Scatter ≤-70dBc
Antenna Integrated helix antenna
Optional microphone
heads
D5 WL1: dynamic (supercardoid)
D7 WL1: dynamic (supercardoid)
C5 WL1: Condenser (cardoid)
Max. sound pressure level DHT800/D5WL1(0dBgain):≤144dBSPL
DHT800/D7WL1(0dBgain):≤140dBSPL
DHT800/C5WL1(0dbgain):≤144dBSPL
Audio input gain
0 dB, +10 dB switchable
Operating time
typ.
6.5hours(2x1.5-VLR6AAbatteries)
typ.6.5hours(2x1.2-VAANiMH
rechargeablebatteries>2100mAh)
Dimensions
37(ø)x170(L) mm
/ 14.6(ø)x67(L) in (without WL1 head)
Net weight
129 g / 4.6 oz
(without WL1 head, no batteries)
5.4 DSR800: Description of the controls
ThefollowingtabledescribesthecontrolsoftheDSR800(gurefrom115):
No. Description
1 POWER: On/off switch
2 DSP button
3 Display
4 BACK button
5 SELECT wheel (turn left/right, press)
DHT800
DSR800 controls
Band 1: 550.1 – 662.9 MHz
Band 2: 730.1 – 831.9 MHz
10, 20 mW (ERP max.), can be set via menu
(country-dependent)
