Harman AKG DHT800 - DHT800: Description of the Controls

eQuiPment descriPtion
DMS800 MANUAL
75
No. Description
9 Battery compartment for 2 LR6 (AA) 1.5 V batteries or 1.2 V
NiMHrechargeablebatteries,sizeAA(>2100mAh)
10 2.5 mm jack socket for external MUTE switch
11 Charging contacts
12 Locking button for battery compartment cover
5.7 DPT800: Description of the display elements
The following table describes the displays of the DPT800
(gurefrom116):
Letter Description
A Alphanumeric name display
B Current group and channel number
C 7‑part status display of the transmitter battery
D Country code or HF level
E Symbol for active encryption
F Symbol for activated muting
5.8 DHT800: Description of the controls
The following table describes the controls of the DHT800
(gurefrom116):
No. Description
1 Display
2 MUTE switch
3 Charging contacts, helical antenna
4 Infrared receiver diode for transmitter synchronization
DPT800 display
DHT800 controls
