eQuiPment descriPtion
DMS800 MANUAL
76
No. Description
5 Status LED (red = warning, green = OK)
6 On/off switch
7 Battery compartment cover
8 Microphone heads D5 WL1, D7 WL1 or C5 WL1
9 Battery compartment for 2 LR6 (AA) 1.5 V batteries or 1.2 V
NiMHrechargeablebatteries,sizeAA(>2100mAh)
5.9 DHT800: Description of the display elements
The following table describes the displays of the DHT800
(gurefrom116):
Letter Description
A Alphanumeric name display
B Current group and channel number
C 7‑part status display of the transmitter battery
D Country code or HF level
E Symbol for active encryption
F Symbol for activated muting
DHT800 display
