Specifications
The following table lists the specifications for the Enova DVX-3266-4K/DVX-2265-4K All-in-One
Presentation Switchers:
Specifications
Power
AC 100-240V 50/60Hz, 10A
Power Consumption
DVX-3266-4K: 90 Watts typical without amplifier, 130 Watts typical average
with amplifier
DVX-2265-4K: 63 Watts typical without amplifier, 103 Watts typical average
with amplifier
Memory
 NVRAM: 1 MB
 Memory Card: 16 GB SD
 DDRAM: 512MB
Note: Supports external USB Solid State Drive
Front Panel Components
PROGRAM (To PC) Port
1 Type-B USB port. Connect to a USB port on a PC and access the NetLinx
Studio program for controller configuration
USB Port:
1 Type-A USB port for connecting a mass storage device for loading .tkn files,
reading or writing configuration files and log files, or updating the firmware
on the unit.
LEDs
 LINK/ACT LED: On indicates that the Ethernet cables are connected and
terminated correctly, and blinking indicates receiving Ethernet data
packets.

STATUS LED: Blinking indicates that the system is programmed and
communicating properly.
 OUTPUT LED: Blinking indicates that the Controller is transmitting data.
 INPUT LED: Blinking indicates that the Controller is receiving data.
 ICSLAN LED: Blinking when the category cable to port 1 is connected and
terminated correctly.
 SERIAL LEDs: Two set of LEDs indicate that the RS-232 port (1-
2) is
transmitting or receiving data.

IR/SERIAL LEDs: Two LEDs, On indicates that IR/SERIAL channels are
transmitting control data on Port (11-12).
 RELAY LEDs: Two LEDs, On indicates that relay channels are active on Port
(21).
 I/O LEDs: On indicates that I/O channels are active on Port (22).
LCD Displays
Liquid crystal display (2 lines with 20 characters per line) indicates current
volume level and displays the Video, Audio, and Status menus.
SWITCH Pushbutton
Press to access the Switch menu on the LCD display. Use the menu to choose
to switch audio, video or both from any input to any output.
TAKE Pushbutton
While in the Switch menu, press to implement an audio/video switch.
V
IDEO MENU
Pushbutton
Press to access the Video menu on the LCD display. There are two video
menus (VIDEO OUTPUT and VIDEO INPUT) and both are accessible by using
this button. Multiple presses cycle through the various VIDEO menus.
A
UDIO MENU
Pushbutton
Press to access the Audio menu on the LCD display. There are three audio
menus (AUDIO OUTPUT, AUDIO INPUT, and MIC) and all are accessible by
using this button. Multiple presses cycle through the various AUDIO menus.
Navigational
Pushbuttons
4 directional buttons for navigating the options in the Switch, Video, Audio,
and Status menus (on the LCD display).
VIDEO MUTE Pushbutton
Press to mute/un-mute (enable/disable) all video output displays.
Video Mute results in a blank screen on the output displays.
AUDIO MUTE
Pushbutton
Press to mute/un-mute all audio outputs. The Pushbuttons light to indicate
that Video muting is active.
STATUS Pushbutton
Press to access the STATUS menu on the LCD display on which you can view
system status and other system information.
EXIT Pushbutton
Press to exit the current menu and return to the default menu page, Main Amp
Output/Volume.
Rear Panel Components
HDMI INPUTs
4 HDMI Type-A Female Connector. Connect to HDMI Sources.
DXLINK INPUTs
 DVX-3266-4K: 4 RJ-45 inputs provide support for digital video, audio,
Ethernet, bi-
directional control, USB, and power over Category Cable
from any DXLink transmitter.
 DVX-2265-4K: 2 RJ-45 inputs
provide support for digital video, audio,
Ethernet, bi-
directional control, USB, and power over Category Cable
from any DXLink transmitter.
HDMI OUTPUTs
 DVX-3266-4K: 4 HDMI Type-A Female Connector. Connect to HDMI
displays.
 DVX-2265-4K: 2 HDMI Type-
A Female Connector. Connect to HDMI
displays.
