When You Receive the Lift
• Check the lift for shipping damage. If you see any damage contact the freight carrier to file a damage
claim.
• Verify the products match that described on the packing list attached to the exterior packaging.
• Verify the contents of the package match that shown below to the right.
Specifications
Payload Capacity 750 lbs
Vertical Travel
54” – 171”
Height
77” – 197”
Foot Print
VARIES
Platform Size
36” x 54” / 36” x 60” / 42” x 60”
Input Voltage
115vac - 20a
Control Voltage
24vac or 24vdc
Platform Speed
10 ft/min
Motor
1/2hp-90vdc or 1/2hp-24vdc
Safety
• Read all instructions in this manual before installing or operating the lift.
• Do not exceed the maximum payload capacity of 750 lbs.
• Do not ride on the lift until it is anchored in place.
• This product is designed only for lifting people and wheel chairs. Do not use it for any other purpose.
• Always wear eye protection while installing or servicing this product.
• Always disconnect this product from the electrical source before servicing it.
• Only use the fasteners supplied with this lift.
• Do not wear loose clothing or jewelry when working on this product.
• Do not disable any safety equipment or switches supplied with this lift.
• Stay away from all drive train components while the lift is operating.
3
