Vantage Stair Lift
INSTALLING THE CHASSIS
q SUPPORT MOUNTING SCREWS ARE SECURE
4. On the front side of the chassis, loosen the three
screws on the seat support using a 9/16" socket. [Figure
22-1]
Figure 22-1
Figure 22-2
5. Rotate the seat support until the top plate is level
and tighten the screws. [Figure 22-2]
