TEC0017 23Jan2015 P/N: 630-00027-01 revC
SL400 • Vantage Stair Lift Installation Manual
25
Vantage Stair Lift
INSTALLING THE CHAIR
7. On the backside of the chassis, there is an on/o
switch. Cut o and discard the shipping tie on the
switch. [Figure 25-1]
8. Turn the switch to the on position. The unit should
beep once when it has completed booting.
q UNIT DOES NOT OPERATE WHEN SEAT IS ROTATED
q SWIVEL LEVER CONTROL LOCKS INTO PLACE IN ALL THREE POSITIONS
Figure 25-1
Figure 25-2
9. Use the armrest control switch to run the lift down
the rail approximately 30”. [Figure 25-2]
NOTE: Refer to page 31 if the unit does not beep once.
