11Features and Specifications NSG Front Panel
Front Panel LEDs
The following table describes the front panel LEDs, from left to right.
LED Color Description
Output Green/Red/
Orange
ON (Green) - Indicates the output port is
properly configured and has at least one
service.
ON (Red) - Indicates an output alarm has been
activated.
ON (Orange) - Indicates an output warning has
been activated.
ON (Green blinking) - Indicates the 'Identify unit'
button has been selected.
OFF - Indicates the output port has no service
or is disabled.
Power Green ON - Indicates that NSG is powered on.
OFF - Indicates that NSG is powered off.
Alarm Red/Orange ON (Red) - Indicates an alarm has been
activated in the device.
ON (Orange) - Indicates a warning has been
activated in the device.
Refer to Chapter 3, “Troubleshooting,” for
further details.
OFF - Indicates no alarm activated.
Input Green/Red/
Orange
The first LED shows the status of GbE channel
1, and the second LED shows the status of GbE
channel 2.
ON (Green) - Indicates the input port is enabled
and has a valid GbE signal.
ON (Red) - Indicates an input related alarm has
been activated. The activated LED indicates the
specific port with the alarm.
ON (Orange) - Indicates an input related
warning has been activated. The activated LED
indicates the specific port with the warning.
ON (Green blinking) - Indicates the 'Identify unit'
button has been selected.
OFF - Indicates the input port is disabled.
