15Features and Specifications Back Panel
The following table lists the GbE port specifications.
The back panel of the NSG features two LEDs for each GbE port. The
following table describes the LEDs:
Parameter Specification
Connector Two receptacles for SFP connectors.
Maximum input bit rate ■
Line rate up to 1000 Mbps.
■
Processing up to 800 Mbps of MPEG data
(up to 256 services).
■
Cascading up to 1000 Mbps of traffic.
LED Color Description
Activity Green
■
Illuminates when a live fiber is
connected to the port and a network
link is detected.
■
Blinks when real traffic flows through
the link.
Alarm Orange Indicates an error in the GbE port.
