32 Preliminary Configuration of the NSG
CHAPTER 2
To configure ETH1 port:
Once you are in Config mode, do the following:
1. Navigate to the Network Config screen and click <Enter>.
The Ethernet Port 1 screen appears.
2. Click <Enter>. The ETH1 IP Address screen appears.
3. Click <Enter>. The Edit IP Address screen appears.
4. Edit the IP address and click <Enter>.
The program checks whether you entered a valid IP address and only
then applies changes. The Edit Ethernet Subnet Mask screen appears.
5. Edit the subnet mask and click <Enter>. The Edit Default GW screen
appears.
6. Edit the ETH gateway and click <Enter.>.
The program checks whether you entered valid network parameters
and only then applies changes. The ETH1 IP Address screen appears.
If invalid network parameters are entered an error message appears.
To configure ETH2 port:
Note: If you are using the ETH2 port, you must configure its IP
address on a different subnet than that of the Ethernet 1 port.
Once you are in Config mode, do the following:
1. Navigate to the Network Config screen and click <Enter>.
2. Click <Down or Up> to open the Ethernet Port 2 screen.
3. Click <Enter>. The ETH2 IP Address screen appears.
4. Click <Enter>. The Edit IP Address screen appears.
5. Enter the required IP address and click <Enter>.
The program checks whether you entered a valid IP address and only
then applies changes. The Edit Subnet Mask screen appears.
6. Enter the required subnet mask and click <Enter>.
