58 Connecting the Power Cable to the NSG
APPENDIX B
3. Connect the DC input power cable to the DC connector on the NSG
back panel, as illustrated in the following figure.
Your NSG is now connected to power.
4. Complete any other cabling that may still be needed, and engage the
disconnect device to start using the device.
Ground connection on
NSG rack
DC connector Ground connection on
NSG back panel
