Chapter 1: DAC-5000 Series Digital Analog Clocks
Rack Mounting
The DAC-5008, DAC-5012 and DAC-5016 clocks can be rack
mounted with the optional rack mounting kit. The kit is installed by
removing the back panel side screws, placing the rack mount in
position, and reinstalling the screws. The rack mount kits are designated
as 5008RM, 5012RM, and 5016RM, respectively.
The DAC-5006 clock is pre-designed to be rack mounted, and does not
require the optional rack mounting kit. It has an overall dimension of
7×19 inches.
Table 1-3 lists the required rack space for each clock.
Table 1-3. Required Space For Rack Mounting
Clocks Rack Units Inches
DAC-5016 10 17.45
DAC-5012 8 13.95
DAC-5008 6 10.45
DAC-5006 4 7
