20 5000/5100 Series Digital Analog Clocks Installation and Operation Manual
Chapter 2: ADC-5100 Series Analog Digital Clocks
Rack Mounting
The ADC-5116, ADC-5112 and ADC-5108 clocks can be rack mounted
with the optional rack mounting kit. The kit is installed by removing the
back panel side screws, placing the rack mount in position, and
reinstalling the screws. The rack mount kits are designated as RM-5116,
RM-5112, and RM-5108, respectively.
The ADC-5106 clock is pre-designed to be rack mounted, and does not
require the optional rack mounting kit. It has an overall dimension of
7×19 inches.
Table 2-11 lists the required rack space for each clock.
Desk Mounting
The ADC-5105 clock can simply be set or mounted on any desk
surface. Its overall dimensions are 8.25 x 5.85 in.
Table 2-11. Required Space For Rack Mounting
Clocks Rack Units Inches
ADC-5116 10 17.5
ADC-5112 8 14.0
ADC-5108 6 10.5
ADC-5106 4 7
