5000/5100 Series Digital Analog Clocks Installation and Operation Manual 13
Chapter 1: DAC-5000 Series Digital Analog Clocks
Mechanical
Table 1-8. Mechanical Specifications
Clock Item Specification
DAC-5016 Style Wall-mount
Face diameter 16 in. (406 mm)
Overall dimensions 17.45×17.45×2.8 in.
(443×443×71 mm)
Weight 9.1 lbs (4.1 kg)
DAC-5012 Style Wall-mount
Face diameter 11.75 in. (298 mm)
Overall dimensions 13.95×13.95×2.8 in.
(354×354×71 mm)
Weight 7.3 lbs (3.3 kg)
DAC-5008 Style Wall-mount
Face diameter 8 in. (203 mm)
Overall dimensions 10.45×10.45×2.8 in. (265×265×71 mm)
Weight 5 lbs (2.3 kg)
DAC-5006 Style Rack-mount
Face diameter 5 in. (127 mm)
Overall dimensions 7×19×2.8 in. (177×482×71 mm)
Weight 4.5 lbs (2 Kg)
DAC-5005 Style Desk-mount
Face diameter 5 in. (127 mm)
Overall dimensions 8.25×6×7.25 in. (209×152×184 mm)
Weight 3.8 lbs (1.75 Kg)
