Harris ADC-5112 User Manual

5000/5100 Series Digital Analog Clocks Installation and Operation Manual 35
Chapter 2: ADC-5100 Series Analog Digital Clocks
Controls
Mechanical
Table 2-18. Controls
Item Specification
Output timecode format SMPTE/EBU
Secondary reference Internal or power line
Second hand movement Step or continuous sweep
Aux. offset Requires one of the following system
clock drivers:
• MTG-3901
• CSD-3901/3902
•CSD-5300
Table 2-19. Mechanical Specifications
Clock Item Specification
ADC-5116 Style Wall-mount
Face diameter 16 in. (406 mm)
Overall dimensions 17.5×17.5×3.375 in. (445×445×86 mm)
ADC-5112 Style Wall-mount
Face diameter 11.5 in. (292 mm)
Overall dimensions 14.0×14.0×3.375 in. (356×356×86 mm)
ADC-5108 Style Wall-mount
Face diameter 8 in. (203 mm)
Overall dimensions 10.5×10.5×3.375 in. (267×267×71 mm)
ADC-5106 Style Rack-mount
Face diameter 5.4 in. (137 mm)
Overall dimensions 8.25×19×6.6 in. (178×483×168 mm)
ADC-5105 Style Desk-mount
Face diameter 5 in. (127 mm)
Overall dimensions 8.25×5.85×7.25 in. (209×145×184 mm)

Harris ADC-5112 Specifications

General

Brand	Harris
Model	ADC-5112
Category	Clock
Language	English
