5000/5100 Series Digital Analog Clocks Installation and Operation Manual 31
Chapter 2: ADC-5100 Series Analog Digital Clocks
MANUAL SET buttons be held for 50 seconds. When adjustments
are complete and the second hand is on the marker, be sure to
release the
CW button after the MANUAL SET button in order to
avoid accidentally entering the Manual Set Mode.
• To move the second hand counter-clockwise, press and hold the
CCW and MANUAL SET buttons together in the following manner:
press and hold the
CCW button first, followed by the MANUAL
SET
button. For every second that the buttons are held, the hands
will move three extra motor points backward. There are 150 motor
points per second; therefore a one second error requires that the
CCW and MANUAL SET buttons be held for 50 seconds. When
adjustments are complete and the second hand is on the marker, be
sure to release the
CCW button after the MANUAL SET button in
order to avoid accidentally entering the Manual Set Mode.
•
