DA-DHR/DH/DSR/DS/HR/H6802+ Installation and Operation Manual 23
Chapter 3: Operation
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Setting Locally Controlled Parameters
Local Control Reclocking Mode
In the local control reclock setting operation mode, all of the settings’
data status information appears on the + Pilot Lite control screen;
however, you cannot change any setting in this mode via + Pilot Lite.
(To control the reclocking setting mode via + Pilot Lite, set the J3
jumper to the remote control reclock setting operation mode.)
For local control, the J1 and J2 jumpers are used to determine
reclocking mode. Table 3-1 describes parameters that are accessible
locally.
Note
Harris recommends that you use
the available 6800+ software
control options (serial / local or
Ethernet / remote) to aid in
viewing, setting, and confirming
parameter values.
Table 3-1. DA-DHR6802+, DA-HR6802+, DA-DSR6802+ Local Control Reclock Modes
Reclock Mode Description
AUTO (Default) Automatically detects the rate; if no selection rate jumpers are selected, the
selection will be AUTO
270 Forces channel to lock to a 270 Mb/s signal
Set the jumper on the pin that allows the reclocker to handle 270 Mb/s data only
• If 270 reclock mode is selected, the 270 Mb/ s LED will turn on
• If the module can successfully lock to the input, the lock LED will turn on
• If reclocking is not successful, the lock LED will turn off and un-reclocked
data will be present at output
1.5HD Set the jumper on the pin that allows the reclocker to handle HD (1.485 Gb/s) data
only
• If 1.5HD reclock mode is selected, the 1.5G LED will turn on
• If the module can successfully lock to the input, the lock LED will turn on
• If reclocking is not successful, the lock LED will turn off and un-reclocked
data will be present at output
3.0HD Set the jumper on the pin that allows the reclocker to handle HD (2.97 Gb/s) data
only
• If 3.0HD reclock mode is selected, the 3.0G LED will turn on
• If the module can successfully lock to the input, the lock LED will turn on
• If reclocking is not successful, the lock LED will turn off and un-reclocked
data will be present at output
BYPASS Forces channel to bypass the reclocker
