Chapter 3: Operation
Setting Remotely Controlled Parameters
Table 3-2 and Table 3-3 on page 25 describe parameters that are
accessible remotely. See your CCS control software application manual
or online help for more information on setting and monitoring these
parameters remotely.
Legend
Bold option=Indicates that this is the default setting for the parameter.
[RO]=Indicates that parameters are read-only/feedback, and cannot be
used to select controls.
All parameters clip unless otherwise noted.
Table 3-2. DA-DH6802+, DA-DS6802+, DA-H6802+ Remotely Controlled Parameters
Name Range Description
Backup mode
• 0 = Disable
•1 = Enable
Loss of signal (input 1) switching enable,
automatically switch both output MUXs to select
input 2 when input 1 has lost its input signal
Output configuration
• 0=1×4
• 1=1×8 ch. 1
• 2=1×8 ch. 2
Allows you to select if the card is in dual 1×4 or 1×8,
with input 1 routed to all outputs; or 1×8 with input 2
routed to all outputs
Signal present [RO]
•0=No
•1=Yes
Indicates if the input is present or not
Slew rate*
•0=HD
•1=SD
•2=Auto
Allows you to specify the slew rate as either HD
(1.485 Gb/s or 3.0 Gb/s) or SD
Loss of input alarm
• 0=Disable
•1=Enable
Enables or disables the Loss of Input alarm
Loss of lock alarm
• 0=Disable
•1=Enable
Enables or disables the Loss of Lock alarm
* DA-DH6802+ only
