34 DA-DHR/DH/DSR/DS/HR/H6802+ Installation and Operation Manual
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Chapter 4: Specifications
Performance
Power Consumption
Module power consumption is < 6 W.
Temperature
Start-Up Time
Module start-up time is approximately 3 seconds.
Table 4-3. Performance Specifications
Item Specification
Jitter 0.2 UI for reclocking DA
0.3 UI for non-reclocking DA (reference only)
Propagation ~ 4.0 ns (for reference only)
Table 4-4. Temperature Specifications
Item Specification
Performance temperature 32° to 122°F (0° to 50°C)
Operating temperature 41° to 113°F (5° to 45°C)
