32 DA-DHR/DH/DSR/DS/HR/H6802+ Installation and Operation Manual
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute.
Chapter 4: Specifications
Inputs
Table 4-1. Input Specifications
Item Specification
Number of inputs
Dual channel mode
1 each channel
Single channel mode
1
Signal type 3.0 G, HD, SD, ASI
Connector BNC per IEC169-8
Impedance 75Ω
Return loss > 15 dB to 1.5 GHz
> 10 dB 1.5 GHz to 3.0 GHz
Maximum signal level ≥ 0.88 V
Cable equalization * For DAs with reclocking
270 Mb/s
0–1,148 ft (0–350 m) Belden 1694A or
equivalent
HD
0–459 ft (0–140 m) Belden 1694A or
equivalent
3.0 Gb/s
0–230 ft (0–70 m) Belden 1694A or equivalent
To Next Page
