MM-014763-001, Rev. E
35
RE
AR
V
IEW
TOP
VIEW
10.5 inches
(267 mm)
2.38 inches
(60 mm)
2.0 inches
(51 mm)
FRONT VIEW
6.9 inches
(175 mm)
(Partial View of
DC Power Cable)
0.8 inches
(20 mm)
Figure 7-1: Front-Mount M7300 Radio Dimensions
