MM-014763-001, Rev. E
8
Based on the highest radiated RF power and the highest antenna gain in antennas to be used with M7300,
the distances listed in Table 1-1 (for VHF radios) and Table 1-2 (for 700 and 800 MHz radios) are
considered as safe distance
s for controlled and uncontrolled environments with the M7300 mobile radio
transmitting at a maximum 50% duty cycle:
Table 1-1: Recommended Minimum Safe Lateral Distance from Transmitting Antenna
Connected to a VHF M7300 Mobile Radio
RECOMMENDED MINIMUM LATERAL HUMAN BODY
DISTANCE FROM TRANSMITTING ANTENNA
ANTENNA
PART NUMBER
(Catalog Number)
ANTENNA DESCRIPTION
CONTROLLED
ENVIRONMENT
(Centimeters)
UNCONTROLLED
ENVIRONMENT
(Centimeters)
AN102800V1
136 to 941 MHz, ¼-Wavelength*,
Standard Rooftop-Mount;
0 dBd Gain
63 140
AN102800V2
136 to 941 MHz, ¼-Wavelength*,
Thick Rooftop-Mount;
0 dBd Gain
63 140
AN-025147-001
136 to 174 MHz,
Standard Rooftop-Mount;
0 dBd Gain
63 140
AN-025147-003
136 to 174 MHz,
GPS Combo Rooftop-Mount;
0 dBd Gain
63 140
AN-025147-005
136 to 174 MHz,
Magnetic-Mount;
0 dBd Gain
63 140
* Driven elements of AN102800V1 and AN102800V2 must be trimmed to proper lengths in order to minimize antenna
system VSWR.
1.3.1 Mobile Antennas
The antenna(s) for the radio must be installed in accordance with Section 6 in this manual. Refer to Figure
6-1 on page 31 for applicable antenna part numbers. Installation guidelines presented in Se
ction 6 are
limited to metal-body motor vehicles or vehicles with appropriate ground planes.
Use only approved/supplied antenna(s) or an approved replacement antenna. Unauthorized antennas,
modifications, or attachments can cause the FCC RF exposure limits to be exceeded.
1.3.2 Approved Accessories
The radio has been tested and meets FCC RF guidelines when used with accessories supplied or
designated for use with it. Use of other accessories may not ensure compliance with the FCC’s RF
exposure guidelines, and may violate FCC regulations. For a list of approved accessories refer to Section
4 in this manual (begins on page 21) and/or the Products and Services Catalog.
1.3.3 Contact Information
For additional information on RF exposure and other information, contact Harris using one of the contact
links listed in Section 3.4 on page 20.
