General Notes about this ManualUser Manual Ha-VIS mCon Switch Management Software
3. General Notes about this Manual
3.1 Explanation of the symbols
The following symbols are used in this software guide:
CAUTION
This symbol describes warning notes that indicate a low-level source of danger. If not avoided,
light or minor injuries or damage to property may result.
ATTENTION
This word describes warning notes that indicate a low-level source of danger. If not avoided,
damage to property may result.
Note
This symbol describes general notes that provide important information concerning one or more
operating steps. Such notes may also provide references to further information supplied within
this manual.
3.2 Typographical conventions
This manual uses the following typographical conventions to describe the software interface:
Italics Text in italic font refers to an entered value, a selection from a drop-
down list (such as Enable), a reference to a section of the software
menu (such as System Settings → General Settings) or drop-down
list choices.
Bold Text in bold font refers to the name of a row or column found within
the software interface, or to the name of a eld where data is
displayed or specied.
3.3 Additional information
Mounting instructions for this switch can be found in the Installation Notes included in the delivery.
The Installation Notes also provide valuable hardware-specic information such as the pin-out
assignments, LED displays, technical specications, and power supply requirements.
The latest versions of the switch rmware and the manual can be downloaded from the Internet
at http://www.HARTING.com.
2. Safety Guidelines and Approved Usage
In order to function properly, the switch management software must be correctly installed and
appropriately operated. The switch management software should be used only in conjunction
with a HARTING Ethernet switch.
Observe the following general safety instructions before installing and using the switch
management software:
• Ensure correct polarity and voltage when connecting the power supply to the Ethernet switch.
• Use only shielded cable for data lines.
• Use only cables that comply with the corresponding standards for Ethernet connections.
ATTENTION
The Ethernet switch should be operated only when it is properly and securely mounted.
CAUTION
Only authorized and qualied personnel are permitted to work on this device!
Improper work or repairs can damage the integrated protective safety functions and the
performance of this device. This can cause the device to malfunction, be a source of personal
danger, or cause damage to connected machines or connected systems.
