Harvia REMOTE START system - Connection to Pro-Serie (Pro B2;3, Pro C2;3, Pro D); Connection to Home.com4

EN
Installation instructions, only for experts p. 9/15
Wm
1
2
3
6
1 2 3 45
5.3. Connection to Pro-Serie (Pro B2/3, Pro C2/3, Pro D)
5.4. Connection to home.com4
ST2
N
ST1
RS1 24VDC
6
45
● Make the setting in the technician menu under menu item Mode RS1.
Connection to S/B....Remote start sauna operation / User program 1
Connection to C/B....Remote start combi operation / User program 2
4
4
