Haskris Model R1600 Preventative Maintenance (PM)
Copyright © 2011 Haskris Company 47 www.haskris.com
Version R1600-X-R407C-XXX Instruction Manual Rev00
Project Name ______________________________ Location ___________________________________
Full Load System
Full Load System Full Load System
Full Load System Check:
Check:Check:
Check: Record Values After System Has Run For 30 Minutes To Stabilize
Record Values After System Has Run For 30 Minutes To StabilizeRecord Values After System Has Run For 30 Minutes To Stabilize
Record Values After System Has Run For 30 Minutes To Stabilize
Electrical
ElectricalElectrical
Electrical
Component
(Check Values at Contactors)
L1
L1
-
L2
L2
L2
-
L3
L3
L1
-
L3
(A)
(V)
(A)
(V)
(A)
(V)
Compressor A
Compressor B
Pump Motor
Fan Motor Inverter
A
(See Section
3.2)
Fan Motor Inverter
B
(See Section
3.2)
Fluid
FluidFluid
Fluid
Supply Water Temperature (ºF)
(PV)
(SV)
Supply Pressure (psi)
Return Pressure (psi)
Bypass/Relief Valve Setting (psi)
Volume of water used (gallons)
Volume of Propylene Glycol used (gallons)
Glycol Solution pH
Glycol Solution % (from Refractometer)
Pump Isolation Valves
Open / Closed
Pump Flush Valves
Open / Closed
Refrigeration
RefrigerationRefrigeration
Refrigeration
Ambient Air Temperature (ºF)
Gauge Suction Pressure (psi) A
Gauge Suction Pressure (psi) B
Gauge Head Pressure (psi) A
Gauge Head Pressure (psi) B
Head Pressure Display (psi) A
(PV)
(SV)
Head Pressure Display (psi) B
(PV)
(SV)
Refrigerant Sight Glass Clear A
YES / NO
Refrigerant Sight Glass Clear B
YES / NO
Refrigerant Moisture Indicator A
Blue / Purple / Orange
Refrigerant Moisture Indicator
B
Blue / Purple / Orange
