BCS6000C-9
CONFIGURATION
The instruments are factory set for a type J thermocouple with a range of 32 to 842°F Use the
following procedure to change thermocouple type or temperature units if required. Detailed
information is given in the vendor literature supplied with the control panel.
Press and hold the SETUP key then press the ▲ arrow key. OPtr will appear in the Upper
Display. Release the SETUP key and press the ▲ arrow key until the Upper Display reads
ConF, then press SETUP.
ULoc will appear in the Lower Display. Press the ▲ arrow until Upper Display reads 20 then
Press the SETUP key to enter the configuration mode.
The lower display should read InPt. Check the sales order for the thermocouple type: Use the
▼/▲ keys to change the value to the corresponding reading below.
J type: -199.9 to 999.9 °F = J.F (Note decimal point between J & F.)
K type: -199.9 to 999.9 °F = ├┘F (Note NO decimal point between ├┘ & F.)
Momentarily press the RESET key. The symbols should stop flashing.
Press the SETUP key to view the other configuration parameters. Use the ▼/▲ keys to change
parameters if required. Press RESET after changes are made to accept the new values.
LOWER DISPLAY
(FUNCTION)
FACTORY
CONFIGURATION
DEFAULT
TYPE J
OPTIONAL
TYPE K
ruL Range Max 999.9 2503
rLL Range Low -199.9 -400.0
OFFS 0.0 0.0 0.0
CtrL Hi Hi Hi
SPuL Range Max 999.9 2503
SPLL Range Low -199.9 -400.0
ALA1 P_Hi P_Hi P_Hi
PhA1 Range Max 999.9 2503
AHY1 0.1 0.1 0.1
ALA2 P-Lo P_Lo P_Lo
PLA2 Range Low -199.9 -400.0
AHY2 0.1 0.1 0.1
USE2 A1_d A1_d A1_d
retP USE3 USE3 USE3
tyP3 0_10 0_5 0_5
ro3H Range Max 842.0 1399
ro3L Range Min 32.0 32.0
diSP EnAb EnAb EnAb
CLoc 20 20 20
After your have completed the Configuration hold the SETUP key and press the ▲ arrow key.
Release SETUP and press the ▲ arrow until OPtr appears in the Upper Display. Press SETUP
once more to return to the normal operating mode.
