64 4000637120 E 06.19 USA / GB
45XA - HLA16PX - 55XA - HLA19PX
C
- Pre-operation inspection
4.2 - ACTIVATION OF CONTROLS
The speed/enable ( 15 ) button at ground or speed/enable ( 6 ) button at platform must be
actived to allow any movement.
Trigger on joystick (if fitted) on platform control box is the Enable switch.
4.3 - FAULT DETECTOR
The machine is equipped with an on-board fault detection system, which indicates the type of
fault to the operator.
The fault is identified by a default code.
The default code is displayed at the ground control box.
According to the type of fault, the machine MAY switch into DOWNONLY mode and certain
movements are prevented to maintain Operator's safety.
Do not use the machine until the fault has been corrected.
4.3.1 - Indicators/LED's test
From the ground control box
From the platform control box
Step Action
1 Pull both the E-Stop buttons ( 10 ) at platform box and ( 6 ) at ground box.
2 Set the key switch ( 1 ) at ground box to the ( 1a ) position.
3 Check that all indicators and the display are lit.
4 Check that the indicators turn off in few seconds, except the (2), (20), (27) and the display (5).
Step Action
1 Pull both the E-Stop buttons ( 10 ) at platform box and ( 6 ) at ground box.
2 Set the key switch ( 1 ) at ground box to the ( 1b ) position.
3 Check that all indicators and the display are lit.
4 Check that the indicators turn off in few seconds, except the (1), (7), (8), (15) and (22).
