94 4000637120 E 06.19 USA / GB
E
- General Specifications
45XA - HLA16PX - 55XA - HLA19PX
2 - Major component masses
N.B.-:-MASSES MEASURED WITH EMPTY TANKS (STANDARD MACHINE-NO OPTIONS).
Note :
• Basket rotate option adds 40 kg (90 lbs) to weight.
3 - Acoustics and vibrations
The acoustics and vibrations specifications are based upon the following conditions :
Component 45XA - HLA16PX
Characteristics-Dimensions SI Imp.
Boom assembly 603 kg 1330 lbs
Turntable assembly 478 kg 1054 lbs
Trailer assembly 1141 kg 2516 lbs
Total weight 2222 kg 4900 lbs
Component 55XA - HLA19PX
Characteristics-Dimensions SI Imp.
Boom assembly 805 kg 1774 lbs
Turntable assembly 463 kg 1020 lbs
Trailer assembly 1455 kg 3207 lbs
Total weight 2722 kg 6001 lbs
Specifications
DC mode - Ground (Lower) 60 dBA
DC mode - Platform (Upper) 55 dBA
Engine mode - Ground (Ground) 70 dBA
Engine mode - Platform (Upper) 65 dBA
