- Operation instructions
45XA - HLA16PX - 55XA - HLA19PX
Operation instructions
1 - Operation
1.1 - INTRODUCTION
• The HAULOTTE® Model 45XA - HLA16PX - 55XA - HLA19PX is a Self-Propelled aerial
work platform, designed and manufactured to position personnel with their tools and
equipment at overhead work locations. The platform load capacity is rated at 227 kg (500
lb). During all aerial work platform operations, four extended outriggers support the unit.
• The aerial work platform drive function has the option to be operated on battery (DC) or fuel
(IC) powered. The boom functions are battery (DC) operated only. This machine is operated
with electronic pushbutton controls, a hydraulic power unit, a hydraulic gear motor and
hydraulic cylinders. The hydraulic power unit includes a reservoir, pump and control valves.
Hydraulic cylinders elevate and extend the telescoping boom and maintain the platform
leveling during operation. The hydraulic motor and mating worm gear allow the telescoping
boom to rotate 360° Non-Continuous around a vertical axis.
• The hydraulic power unit uses a 24-Volt DC, one horsepower DC motor to drive the
hydraulic pump.
• The DC motor is powered by four 6-Volt DC, 260 Ah deep charge batteries connected in
series.
• An automatic onboard battery charger is provided for recharging the batteries at the end of
each work period.
• The liquid cooled Kubota (IC) engine can be fueled by: Gas ( 32HP (24kW)), Dual Fuel (Gas
/ LP 32HP (24kW) ), or Diesel ( 24HP (18kW)).
• The ground (lower) control box controls the power, outriggers, boom lift elevation, and
rotation functions.
• The platform (upper) control panel also controls the power, outriggers, boom lift elevation,
rotation functions, and drive functions.
N.B.-:-T
HE ELEVATION AND ROTATION CONTROLS ARE OPERATIONAL ONLY WHEN THE OUTRIGGERS
ARE
CORRECTLY EXTENDED AND THE EXTENSION BOOM IS WITHIN A PROGRAMMED SAFE OPERATING
ZONE
.
