HAWA Concepta 40/50
7.2
DE Berechnung: Masse Grundriss
FR Calcul de : Dimensions plan d'ensemble
EN Calculation: Plan view dimensions
IT Calcolo: Dimensioni di pianta
S N1N2N3N4
19- 30 mm ( "-1 ") 55 mm (2 ") 0 mm 0 mm 0 mm
33 mm (1 ") 58 mm (2 ") 0 mm 3 mm ( ") 3 mm ( ")
36 mm (1 ") 63 mm (2 ") 2 mm ( ") 6 mm ( ") 5 mm ( ")
39 mm (1 ") 67 mm (2 ") 3 mm ( ") 9 mm ( ") 8 mm ( ")
42 mm (1 ") 70 mm (2 ") 3 mm ( ") 12 mm ( ") 11 mm ( ")
45 mm (1 ") 75 mm (2 ") 5 mm ( ") 15 mm ( ") 14 mm ( ")
48 mm (1 ") 79 mm (3 ") 6 mm ( ") 18 mm ( ") 17 mm ( ")
50 mm (1 ") 83 mm (3 ") 7 mm ( ") 21 mm ( ") 19 mm ( ")
