18
Restart Temperature
Without BBWC: not used.
With BBWC: Defines the temperature at which the charge will restart, if the programmed limit is reached, and
the charge stops.
Charge Profile
Select Fast, Opportunity, or Ionic. This setting will be overridden by the BBWC programming
so make sure the BBWC is set to tell the charger the profile you desire the charger to run.
Ionic Charge Coefficient
This is only accessible through high level password.
If you do have access to this setting make sure you understand what you are doing. If adjusted incorrectly it
could eventually damage a battery if not corrected.
This is the amount of overcharge built into the Ionic charge profile to compensate for losses in the battery
during recharge. (factory set to 15%, means total of 115%)
AGV_offset
For AGV applications, enter amount of Amps onboard electronics draw during charging. Allowed range is 0 to
20A. Entering 0 disables
erord
Equalize Days
Select day or days of the week to equalize the battery. You may select none, or as many days as you need.
Equalize Time
Equalize Time of Day: Sets the time of day the Equalize charge will start (24hr clock).
Equalize Delay: Sets the delay between the normal charge and the equalization charge from 0 to 24 hrs.
Equalize Duration
Sets the equalization time from 00:01 to 23:59. (hh:mm)
erord
