HBM AE101 - 4.2 AE301 Measuring amplifier

19
Clip
HBMA0114-6.3 en
• Measuring frequency range
The measuring frequency range is 10 Hz.
• Zero point
- Discharge the transducer or charge with preload.
- Use digital voltmeter to measure output voltage, and use rotary switch S23
to adjust minimum indication (if necessary, use S22 to switch polarity); fine
balancing with P21 to 0.000 V.
• Measuring range
To obtain the maximum measurement resolution, the max. amplifier output-
voltage ("10 V) should be used.
AE301
V
E
= 2.5 V V
E
= 5 V switch position S21
mV/V mV/V 1 2 3 4 5 6 7 8
0.34-0.48 0.17-0.24 X X
0.44-0.64 0.22-0.32 X X
0.60-0.84 0.30-0.42 X X
0.78-1.1 0.39-0.55 X X
1.04-1.46 0.52-0.73 X X
1.36-1.94 0.68-0.97 X X
1.80-2.56 0.90-1.28 X X
2.36-3.38 1.18-1.69 X X
3.12-4.46 1.56-2.23 X X
4.14-5.88 2.07-2.94 X X
5.46-7.76 2.73-3.88 X X
7.22-10.26 3.61-5.13 X X
Tab. 4.2: Nominal measured value depending on the bridge excitation voltage V
E
Factory setting: V
E
= 5 V; M
R
= 2 mV/V
