Connecting digital inputs/outputs
HBM AED9301B
IMD = 2 (Dosing mode, also see aed_help_e, AD103C; “Description of the commands for the
filling and dosing applications”):
The following output functions are available, subject to the output mode command (OMD):
Outputs OMD0 OMD1 OMD2
OUT1
Coarse Flow Coarse Flow Coarse Flow
OUT2
Fine flow Fine flow Fine flow
OUT3
Ready signal /
emptying
1)
Ready signal /
emptying
1)
Ready signal /
emptying
1)
OUT4
Tolerance+ overrun
Outside Tolerance 
Alarm
1)
for emptying time = 0 (EPT)  OUT3 ready signal is after actual value determination,
for emptying time > 0 (EPT)  OUT3 emptying control is over set time
