HBM C9B - 8 Dimensions

17
C9B
A2088-3.0 en/de/fr HBM
8 Dimensions
R
∅U
H
B
T
J
G
A
Y
X
Cable ∅3; 1.5 m long
Min.
bending
radius R10
Dimensions in mm (1 mm = 0.03937 inches)
Nominal (rated
force) C9B
A
‐0.1
B G
±
0.1
H J R T U
‐0.1
X Y
50 … 200N
26 15 20.5 3xM3 6 20 2.5 5.5
approx.
10.5
approx.
5.5
0.5 … 20 kN
26 13 22.75 3xM2 3.5 40 1 8
approx.1
0.5
approx.
5.5
50kN
46 28 40 4xM4 6 80 8 16
approx.1
0.5
approx.
5.5
