1 Scope of supply
• 1 Force transducer C9B
• 1 Mounting instructions
• 1 Manufacturing certificate
2 General application instructions
Force transducers in the C9B type series are suitable for measuring compres
sive forces. Because they provide highly accurate static and dynamic force
measurements, they must be handled very carefully. Particular care must be
taken when transporting and installing the devices. Dropping or knocking the
transducers may cause permanent damage.
The relatively thin housing top and base must not be damaged, otherwise the
transducer will become useless, see section 3.2 on Page 9.
The specifications list the permissible limits for mechanical, thermal and elec
trical stress. It is essential that these are taken into account when planning the
measuring set‐up, during installation and ultimately, during operation.
