15
U2A
HBMA1261−2.2 en/de/fr
Knuckle eye below ZGUW
a.f.
Material: tempering steel, galvanized; rolled steel and PTFE/bronze fabric foil
Center of
bearing
Max.
capacity
in t
Knuckle eye
ZGUW
Weight
in kg
A ∅B D F G H M a.f. W X
0.05...1 U2A/1T/ZGUW 0.1 33 12
H7
32 54 70 12 M12 19 16 7
2 U2A/2T/ZGUW 0.2 47 20
H7
50 78 103 18 M20x1,5 32 25 9
5 U2A/5T/ZGUW 0.4 57 25
H7
60 94 124 22 M24x2 36 31 10
10 U2A/10T/ZGUW 1.1 65.5
50
+0.002
-0.014
115 148.5 210 28 M39x2 60 35 16
20 U2A/20T/ZGUW 3.2 80
60
+0.003
-0.018
126 168 236 36 M48x2 70 44 18
