Heath Zenith 4300 - Wiring Configurations and Grounding; Recommended Grounding Method; Other Wiring Options

3
204062-01
GroundScrew
WhitetoWhite
BlacktoBlack
Recommended Grounding Method
One Motion Sensing Light
Two Motion Sensing Lights (Working Independently)
Other Wiring Options
Thisxturecanbewiredtocontrolanotherstandard
ormotionsensinglightxture(s).Seethefollowing
wiringdiagramsforproperconnections.
Note:Allwiringshouldberuninaccordancewith
the National Electrical Codethroughconduit or
anotheracceptablemeans.Contact a qualified
electrician if there is any question as to the
suitability of the system.
BlacktoBlack
WhitetoWhite
Ground
toGround
BlacktoBlack
WhitetoWhite
GroundtoGround
MetalJunction
Box
Pigtail(not
supplied)
FixtureBare
GroundWire
BareGroundWire
Wiring Motion Sensing Light to Control Standard
Fixture
Groundto
Ground
StandardLightFixtureMotionSensingLight
BlacktoBlack
WhitetoWhite
RedtoBlack
Maximum Load for
Motion Sensor –
200 Watts
Maximum Lamp
Wattage Rating
for Light Fixture –
100 Watts
Maximum Lamp
Wattage Rating
for Light Fixture –
100 Watts
TOTAL Load for
Motion Sensor –
200 Watts
CONTROLLING Fixture
CONTROLLED Fixture 1
Whencontrollinganadditionallightxture(s),the
maximumwattageofthemotionsensoron this
xtureshouldbeobserved.Seeillustrationbelow
foranexampleofamaximumlampwattageload
calculation.
IMPORTANT: When determining the maximum
lampwattageratingofthexturetobecontrolled,
refertothemaximumlampwattagelabelonthe
xtureandnotthewattageratingonthelamp(s)
currentlyinstalledinthexture.
Wiring Motion Sensing Light to Control Another
Motion Sensing Light
BlacktoBlack
WhitetoWhite
GroundtoGround
BlacktoRed
and Black
RedtoBlack
ControlledMotion
SensingLight
MotionSensingLight
