Heath Zenith 4300 - Coverage Area Adjustment; Sensor Sensitivity to Motion; Adjusting Coverage Area; Specifications

5
204062-01
Least Sensitive Most Sensitive
The sensor is less sensitive to motion directly
towardsit and moresensitive to motion across
coveragearea.
Sensor
Motion
Motion
SPECIFICATIONS
Range...........................Upto30ft.(9.1m)
[varieswithsurrounding
temperature].
SensingAngle.............. 360°
ElectricalLoad..............Upto100Watt
MaximumTungsten
Incandescent(Upto25
WattMaximumeach
lampholder).
BulbType...................... CandelabraBase,Type
“B”,25WattMaximum
SensorCapacity...........Upto200Watt(1.7A.)
MaximumTungsten
Incandescent
PowerRequirements.... 120VAC,60Hz
OperatingModes..........TEST,AUTO/ACCENT,
andMANUALMODE
ON-Timer......................1,5,10minutes
DualBrite
®
Timer..........Off,3,6Hrs,Dusk-to-
Dawn
HeathCo LLC reserves the right to discontinue
productsandtochangespecicationsatanytime
withoutincurringanyobligationtoincorporatenew
featuresinproductspreviouslysold.
ADJUSTMENT OF COVERAGE
AREA
Thesensor onthis light xturedetects“motion”
bythemovementofheat(bodyheat)acrossthe
coveragearea.However,followingareexamples
ofobjectsthatalsoproduceheatandcancause
thesensortofalsetrigger:
•PoolsofWater •AirConditioners
•DryerVents •Fenced-InAnimals
•HeatingVents •AutomobileTrafc
Ifyoususpectthataheatsourceofthistypeisfalsely
triggeringthesensorandreducingthesensitivity
does not solve the problem, then a lens shield
(included)can be installed.Theplasticlensshield
isdividedinto6sections.Eachsectionwillreducethe
coverageangleby30degrees.Also,thetipofeach
sectionmaybe removedtochange the effective
rangeofthesensor.
1. Break off the
amountoflens
shield needed
toblockthede-
sired area of
coverage.
2. Cut desired
amountoffoam
tapeneededto
adherethelens
shieldtothesensorlens.
3. Removepaperbackingfromonesideofcut
foamtapeandadherefoamtapetoinsideof
lensshield.
4. Removepaperbackingfromothersideofcutfoam
tapeandadherelensshieldtosensorlens.
5. Retesttoconrmthatthesensorisnolonger
falsetriggering.
Note:To help determine amount of lens shield
required,applysmallsectionsoneatatime.Ad-
ditionalsectionscanbeappliedifnecessary.
Area
Blocked
Area
Blocked
Lens
Shield
Lens
Shield
Portion
Removed
Effective
CoverageArea
(TopView)
LensShield
SensorLens
DUAL BRITE
®
ON-
TIME
TEST 1 5 10 MIN
OFF 3 6
DUSK
TO DAWN
