Heath Zenith 4300 - Testing and Adjustment; Testing Procedure; Sensitivity Adjustment; Setting On-Time and Accent Mode

4
204062-01
TESTING
1. Turn on the circuit breaker and light switch.
Note:Sensorhasa1
1
/
2
minutewarmupperiod
beforeitwilldetectmotion.Whenrstturnedon
wait1
1
/
2
minutes.
2. SettheON-TIMEswitchtotheTESTposition
andtheDualBrite
®
switchtotheOFFposition.
3. Walkthroughthecoverageareanotingwhere
youarewhenthelightsturnon.InTESTmode,
lightwillstayonforonly5secondsthenturn
off.
4. AdjusttheSENSITIVITYtoincreaseordecrease
therangeasneeded.Toomuchsensitivitymay
causefalsetriggeringduetoheatsourcesinthe
coverage area (see Adjustment of Coverage
AreaorTroubleshootingsection).
Itisalsopossibletowiretwomotionsensinglights
sothateitherunitwillturnonbothlightsatthesame
time(dualcontrolledsystem).Itisrecommendedthat
onlypeoplewithelectricalwiringexperienceattempt
thisconguration.Pleasecallourcustomerservice
number (1-800-858-8501) before attempting this
wiring.If the dual controlled wiring is not done
correctly, it can destroy both motion sensing
fixtures and void your warranty.
INSTALL FIXTURE BASE TO
JUNCTION BOX
1. Pushwiresintothejunctionbox.
2. Slide lightxture base onto xture screwsand
tightendecorativenutssnuglyagainstthebase.
3. Install four candelabra base light bulbs (25
Watts maximum each).
4. Refer to TESTING section before installing
cover.
5. Afterswitchesaresetandtestingiscomplete,
usethe2decorativenutstoinstallthecover.
DUAL BRITE
®
ON-TIME
TEST 1
5 10 MIN
OFF 3 6
DUSK
TO DAWN
DualBrite
®
ON-TIME
DUSK
OFF
3 HR 6HR TO DAWN
TEST 1 5 10 MIN
Sensor
Lens
5. SettheamountofON-TIMEyouwantthelight
tostayonaftermotionisdetected(1,5,or10
minutes).
6. Settheamountoftimeyouwantthelightto
stayonintheAccentmode(Off,3hours,6
hours,ordusk-to-dawn).
SENSITIVITY
+
–
+
–
SENSITIVITY
DUAL BRITE
®
ON-TIME
TEST 1
5 10 MIN
OFF 3 6
DUSK
TO DAWN
FixtureScrew
JunctionBox
DecorativeNut
25WattCandelabra
BaseBulb
Maximum Range Coverage Angle*
(Top View)
360°
30Feet(9.1m)
inallDirections
*Withoutlensshieldinstalled.
8ft.(2.4m)
