-5-

598-1143-02

Removescrewto

open access door

BackofChime

4. To change the code, either:

• Addajumpertothesamelocationonboththepushbuttonandthechime

or...

• Removeajumperfromthesamelocationonboththepushbuttonandthe

chime or...

• Moveajumperonthepushbuttonfromonelocationtoanother.Movethe

correspondingjumperonthechimetomatchthenewlocationinthepush

button.

 Example:Movejumperatlocation“5”tolocation“4”onboththepush

button and the chime.

Note: Code positions 1 through 7 must be exactly the same for both the

push button and chime for this system to function.

Note:Unitwillcomefactorysetwithjumpersinlocations5,6,and7onthe

push button and on the chime (see Figure 5).

The range of the wireless chime can vary with location,temperature, and

battery condition.

* Code Settings 1-7

MustMatchBothPush

ButtonandChime

InsidePush

Button

Note: Some models might require the use of

tweezerstoremoveandreplacethejumpers.

Figure 5

12345678

VOLUME

1234567
